American DJ® - www.americandj.com - VioMoon LED Instruction Manual Page 13 American DJ® - www.americandj.com - VioMoon LED Instruction Manual Page 14
Master-Slave Operation: This function will allow you to link up to 16
units together and operate without a controller. The units will be sound
activated. In Master-Slave operation one unit will act as the controlling
unit and the others will react to the controlling units programs. Any unit
can act as a Master or as a Slave.
1. Using standard XLR microphone cables, daisy chain your units
together via the XLR connector on the rear of the units. Remem-
ber the Male XLR connector is the input and the Female XLR
connector is the output. The rst unit in the chain (master) will use
the female XLR connector only - The last unit in the chain will use
the male XLR connector only. For longer cable runs we suggest a
terminator at the last fixture.
2. On the Master unit set your desired operating mode.
3. On the slave units press the MENU button until “SLND” is dis-
played, and Press ENTER.
4. Either “SL 1” or “SL 2” will be displayed, select either one of the
slave modes and press ENTER. The slave unit will now follow
the Master unit. Please see below for an explanation of the 2
Slave modes.
Slave Modes: When running fixtures in Master/Slave configura-
tion “SL 1” will make the fixture do the opposite to the a fixture
set to “SL 2”. Example: If Four fixtures are linked together. For
fixtures 1 and 3 set the fixtures to “SL 1”, and set fixtures 2 & 4 to
“SL 2”. Fixtures 1 & 3 will run the same and fixtures 2 & 4 will run
opposite. This makes a great light show.
5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
VioMoon LED UC3 Control
Channel Value Function
1 SHOWS
0 - 9 BLACKOUT
10 - 49 SHOW 1
50 - 89 SHOW 2
90 - 129 SHOW 3
130 - 169 SHOW 4
170 - 209 SHOW 5
210 - 249 SHOW 6
250 - 255 SOUND ACTIVE
VioMoon LED 1 Channel DMX Mode - Values & Traits
Stand by
Blackout the unit
Function
1. Synchronous Strobe
2. Sound Strobe in white
3. Sound Strobe in color
Select Color
1.Red
2.Green
3.Blun
4.White
5.R+G
6.R+B
7.R+W
8.G+B
9.G+W
10.B+W
11.R+G+B
12.R+G+W
13.R+B+W
14.G+B+W
15.R+G+B+W
16.Color change by
sound
Select show
1-6
Mode
Strobe (LED OFF)
Show (LED ON) LED blinking
VioMoon LED Master-Slave Operation
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 12 xtures maximum. After 12 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.
VioMoon LED Power Cord Daisy Chain
