INTERNAL MENU
©American Audio® - www.AmericanAudio.us - Radius 1000™ Instruction Manual Page 17
Press and hold the folder knoB (20) for at least 2 sec. to enter the internal menu.
Press the time (28) or ratio (23) knoBS to enter the submenus and to confirm setting; press the
folder knoB (20) to exit the menu.
1. JOG MODE - Select JOG LED mode (mode range is 1~8)
2. Sensitivity - Touch Wheel Sensitivity Adjustment (Adjustment range is -20~+20)
3. Pitch Bend - Pitch range +/-1%~100%
4. Display Time - Range is 0.5~12.0 sec.(LINE NAME start / stop time adjustment)
5. Scroll Speed- Line Name Scroll Time Adjustment (Scroll Time Range is 50~2000msec.)
6. SLEEP Time - Sleep Time Adjustment (Adjustment Range is 5~120 min)
7. INTENSITY - VFD Brightness (Brightness Range is 1~10)
8. A.CUE LEVEL - Change the AUTO CUE Level (Level Range is -36~-78db)
9. MIDI CC TYPE - Change the send of REL.(RELATIVE), ABS.(ABSOLUTE), Note for
FOLDER/TRACK/PARAMETER TIME/PARAMETER RATIO/ PITCH under MIDI
mode. PITCH is sent by BEND(PITCH BEND)/ ABS.(ABSOLUTE).
A. MIDI CH - Change Chan 1~16 or control Chan(1~8,9~16) by BEAT
B. MIDI SETUP - Dual control ON/OFF, The CD can be controlled by JOG, & Pitch Bend, Pitch ON/
OFF, & Pitch Percentage, when using MIDI mode.
-TAP = HOLD/TOGGLE
-JOG OUTPUT (0~30 ms) (Control JOG MIDI max. send time)
-Pluse = (1024 or 512) (select sensor to send Pluse)
-I/O DISPLAY/Hide (display/hide MIDI I/O value)
-USB Reset (reset USB)
C. Bit Rate - Disp ON
Disp OFF
D. Version - CON: VerXX( control version)
SER: VerXX( Servo version)
BUF: VerXX( Buffer version)
DSP: VerXX( DSP version)
E. Defaults - YES?(return to default value?)
NO?(exit without returning to default value)
F. EXIT & SAVE - Exit & Save setting to next power on (Press the Memory Button to fast exit &
save in any operating mode)
G. EXIT - Exit without save(press FOLDER KNOB for instant EXIT).
Note:
Save: PITCH ON/OFF, PITCH RANGE, SGL/CTN, AUTO CUE, TIME MODE, HOLD, KEY LOCK,
EFFECTS ON/OFF, SENITIVITY, SLEEP/STOP/RUN TIME/ JOG MODE/ INTENSITY/ A.CUE LEVEL/
SEARCH SPEED/ MIDI CC TYPE/ MIDI CH/ MIDI SETUP
Defaults: PITCH (ON), PITCH RANGE (8%), (CTN), AUTO CUE(ON), TIME MODE (REMAIN),
HOLD(OFF), KEY LOCK(OFF), EFFECTS(OFF), SENITIVITY(+05), SLEEP(15min)/ STOP(3 sec)/
RUN(400msec) TIME, PITCH BEND(PITCH RANGE), BIT RATE(Disp. ON), JOG MODE(MODE1,6),
INTENSITY(10), A. CUE LEVEL(-48db), MIDI CC TYPE(REL.) PITCH(BEND), MIDI CH(CH 1), MIDI
SETUP(JOGOUT 0 ms) (I/O HIDE), DUAL CONTROL OFF (PULSE 1024)
