Model: Q-SPAND 4 Channel Mixer
POWER SUPPLY: AC 115/230V, 50/60Hz Selectable
DIMENSIONS: 482 x 176 x 72mm
WEIGHT: 7.5 Lbs. / 2.8 kg
CROSSFADER: Feather Fader Plus - VCA detecting fader start control -
Low grounding impedance crossfader
POWER CONSUMPTION: 5W typical, 7W w/ full headphone output
HEADPHONE IMPEDANCE: 16 Ohms
ENVIRONMENTAL CONDITION: Operating Temperature: 5 to 35 deg. C; Humidity: 25 to 85% RH
(non-condensing); Storage Temperature: -20 to 60 deg. C
Input Sensitivity (Level/Impedence): LOAD=47K OHM
LINE: -14dBV / 10K Ohm ±3dB
PHONO: -50dBV / 47K Ohm ±3dB
MICROPHONE: -54dBV / 3K Ohm ±3 dB
AUX: -14dBV / 47K Ohm ±3dB
Output Sensitivity (Level/Impedence): Note: 0dBV=1Vrms
MASTER OUT (XLR): 0dBV /470 Ohm ±3dB
REC OUT (RCA): -5.5dBV /1K Ohm ±3dB
PHONES (LOAD=32 OHMS): -2dBV /33 Ohm, PGM IN ±3dB
-3dBV / 33 Ohm, CUE IN +/-3dB
Maximum Output (Load = 47K, THD = 5%)
MASTER/ZONE: More than 18dBV (8V)
PHONES (Load=32 ohms): More than 4.6dBV (1.7V)
CHANNEL BALANCE: WITHIN 3dB
Frequency Response:
LINE/AUX: 20Hz - 20KHz, ±2dB
PHONO: 20Hz - 20KHz, +2/-3dB (RIAA)
MICROPHONE: 20Hz - 20KHz, +2,-3dB
Output Noise (IEC-A WEIGHTED):
LINE/AUX: LESS THAN -70dBV
PHONO: LESS THAN -65dBV
MIC: LESS THAN -55dBV
THD - Total Harmonic Distortion (1Khz, 0dBV Output):
MASTER OUTPUT (LOAD = 47K OHMS): LESS THAN 0.2%
PHONO: (LOAD = 32 OHMS): LESS THAN 0.3%
CROSS TALK: More than 40dB
Channel Equalizer:
BASS: +12 ±3dB / Less than -25dB at 70Hz
MID: +12 ±3dB / Less than -18dB at 1KHz
TREBLE: +11 ±2dB / Less than -12dB at 13KHz
Microphone Equalizer:
BASS: +12 ±2dB / Less than -20dB at 70Hz
TREBLE: +12 ±2dB / Less than -15dB at 13KHz
Q-SPAND™ Specifications
©American Audio® - www.americanaudio.us - Q-SPAND™ Instruction Manual Page 16
