©American DJ Supply® - www.americandj.com - Pro Par56 CWWW User Manual Page 10©American DJ Supply® - www.americandj.com - Pro Par56 CWWW User Manual Page 9

Pro Par56 CWWW Operating Instructions

programs. Any unit can act as a Master or as a Slave however, only

one unit can be programmed to act as the “Master.”

Master-Slave Connections and Settings:

1. Daisy chain your units via the XLR connector on the rear of

the unit. Use standard XLR microphone cables to link your

units together. Remember that the Male XLR connector is the

input and the Female XLR connector is the output. The first

unit in the chain (master) will use the female XLR connector

only. The last unit in the chain will use the male XLR

connector only.

2. You will also have to link the power cords to each other, as you

did with the XLR cables.

3. Using the Master unit, choose your desired mode and connect

the “Slave” unit or units.

4. Set the “Slave” unit(s) to the DMX mode. So all “Slave” units dis-

play “1001”. They will now follow the “Master” unit.

Pro Par56 CWWW 4 Channel DMX Mode

Channel Value Function

1 0 - 255 COOL WHITE (CW)

0% - 100%

2 0 - 255 WARM WHITE (WW)

0% - 100%

3 WHITE PRESET TEMPERATURES

0 OFF

1 - 13 3400K

14 - 27 3800K

28 - 41 4000K

42 - 55 4300K

56 - 69 4600K

70 - 83 4800K

84 - 97 5000K

98 - 111 5100K

112 - 125 5400K

126 - 139 5600K

140 - 153 5800K

154 - 167 6000K

168 - 181 6200K

182 - 195 6400K

196 - 209 6600K

210 - 223 6800K

224 - 236 7000K

237 - 248 7200K

249 - 255 7400K

4 0 OFF

1 - 255 STROBING SLOW - FAST

Color Temperature Presets:

Preset # Color Temperature

Cool White Warm White

19 7400K 255 2

18 7200K 255 11

17 7000K 255 20

16 6800K 255 30

15 6600K 255 42

14 6400K 255 56

13 6200K 255 72

12 6000K 255 91

11 5800K 255 113

10 5600K 255 138

9 5400K 255 170

8 5100K 255 231

7 5000K 255 255

6 4800K 204 255

5 4600K 161 255

4 4300K 106 255

3 4000K 61 255

2 3800K 35 255

1 3400K 0 255

DMX Values

Pro Par56 CWWW Operating Instructions
