©American Audio® - www.americanaudio.us - M1224FX Instruction Manual Page 17
2
3
1
T R S
2
3
1
2
3
1
(XLR)
(XLR)
White(Red)/HIGH
A. XLR**
B. TRS PHONE
Black/LOW
Shield/GND
White(Red)/HIGH Black/LOW
Shield/GND
T S
T TSS
2
3
1
(XLR)
(Standard Phone)
D. STANDARD
PHONE
E. SHIELD/GND
PHONE
White(Red)/HIGH Black/LOW
Shield/GND
White(Black)/HIGH
Shield/GND
T S
2
3
1
(XLR)
C. STANDARD
PHONE
White(Red)/HIGH Black/LOW
Shield/GND
Floating or Balanced
low impedance: most
professional equipment
line in and line out,
microphones.
Unbalanced
low impedance: some
professional equipment
and microphones.
Unbalanced
high impedance: most
hi-fi equipment.
Unbalanced
high impedance: most
hi-fi equipment.
REMOTE DEVICE REMOTE SIDE OF CABLE
DESCRIPTION CABLE (Connector Type)
M1224FX CONNECTORS
Connector and Cable Congurations
Connector and cable congurations are recommended for use with the M 4 bus series. These cables
are based on the use of auxillary equipment that is isolated from the AC power mains.
