Model: American Audio® CPX 10A
Dimensions: 13.75” (L) x 12.75” (W) x 20.5” (H) / 347mm x 320mm x 516mm
Weight: 40 Lbs. / 17.95 kgs
Fuse: 7 Amp
Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)
Operational humidity: 25 to 85% RH (non-condensation)
Storage temperature: -20 to 60˚C (4 to 140˚F)
Frequency Response: 30Hz - 18KHz
Nominal Dispersion: 90° x 60°
Built-In Bi-Amplifier: 250W
Amplifier Section:
Power supply: AC 115v/60Hz or 230v/50Hz
Accessories: I.E.C. Power Cord
Low Frequency: 10” (255mm), 2” (50mm) Voice Coil
High Frequency: 25mm Voice Coil, 1” (25mm) Throat
Input Sensitivity:
Line: 0.5V
Mic: 9m V
Output Sensitvity: 93dB(1m/1w)
Max. SPL: 114dB
Input Impedance:
Balanced: Line 20K Ω, Mic 3.6K Ω
Unbalanced: Line 10K Ω, Mic 1.8K Ω
Crossover:
Low Pass: 2nd Order Filter 2.7KHz @ 12dB/octave
Low Cut: 2nd Order Filter 30Hz @ 12dB/octave
S/N Ratio: Line 100dB, Mic 80dB
Channel Equalizer:
Bass: 100Hz +12dB
Treble: 10KHz +12dB
CPX Speakers Technical Specifications
©American Audio® - www.AmericanAudio.us - CPX Speakers - Instruction Manual Page 14
