©American Audio® - www.AmericanAudio.us - CDI-300™ Instruction Manual Page 13
GENERAL FUNCTIONS AND CONTROLS (Cont.)
Figure 6
D. LCD DISPLAY PANEL (FIGURE 5)
30. PAUSE INDICATOR - This indicator will glow
when the drive is in pause mode.
31. MEMORY BUCKET INDICATOR - This indi-
cator serves two functions. The bucket outline
details the cue memory status, a full bucket
outline indicates the cue memory is full. The four
bars in the memory bucket detail the anti-shock
memory state. Each bar indicates 2 seconds of
digital anti-shock. The search functions will not
operate until all the bars are full.
32. CUE INDICATOR - This indicator will glow
when the unit is in CUE or mode and will flash
every time a new CUE POINT is set.
33. PITCH METER - This meter will display the
pitch percentage applied by the
PITCH SLIDER
(5).
34. TIME BAR INDICATOR -
This bar gives a
visual approximation of a track's or disc's remain
-
ing time. This bar will begin to flash when a CD
is ending, or a track if the unit is in "SINGLE"
mode.
35, 36, 37. TIME DISPLAY -
These indica-
tors detail the Minutes, Seconds, and Frames.
The meter will display either the elapsed, total,
or remaining time of a track or disc. The time
displayed in the meter will directly reflect the
time indicator above TOTAL REMAIN (39), OR
REMAIN (38).
38. REMAIN INDICATOR - When "REMAIN"
is indicated in the LCD DISPLAY (22) the
TIME
DESCRIBED (35, 36, & 37)
in the LCD will define
the current track's remaining time.
39. TOTAL/REMAIN INDICATOR -
When
"TOTAL" and "REMAIN" are indicated in the
LCD DISPLAY (22)
the TIME DESCRIBED (35,
36, & 37)
in the LCD (22) will define the total disc
remaining time.
40. RELOOP INDICATOR - Appears when LOOP
is engaged or ready to be engaged.
41. LOOP - This icon will flash when you are in
loop mode. This icon will glow when a loop has
been created but is not actively playing.
42. SINGLE INDICATOR - This indicates that the
CD drive is in single play mode, the track will play
once and return to CUE mode. If the single indi
-
cator is not on the unit is in continuous mode In
continuous mode the drive will play all the remain
-
ing tracks on the disc. Once the remaining tracks
have ended the unit will return to cue mode
43. CD DIRECTION INDICATOR - Indicates the
direction the CD is rotating. Counter-Clockwise
rotation means the CD is playing in reverse.
44. TRACK INDICATOR - This 2-digit indicator
visually details the current track cued or playing.
45. PLAY INDICATOR - The "PLAY" indicator will
glow when the unit is in play mode.
30
42
41
40
39
38
37
36
35
34
33
32
31
45
44
43
