American DJ® - www.americandj.com - Accu Spot Pro Instruction Manual Page 45
Accu Spot Pro DMX Traits cont.
American DJ® - www.americandj.com - Accu Spot Pro Instruction Manual Page 46
Channel Value Function
11 SHUTTER & STROBE CONT.
160 - 191 SHUTTER OPEN
192 - 223 RANDOM STROBE EFFECT
SLOW - FAST
224 - 255 SHUTTER OPEN
12 DIMMER (INTENSITY)
0 - 255 INTENSITY
0% - 100%
13 SPEED OF PAN/TILT MOVEMENT
0 - 225 SPEED MAX - MIN
226 - 235 BLACKOUT BY MOVEMENT
236 - 245 BLACKOUT BY ALL WHEEL CHANGE
246 - 255 NO FUNCTION
14 LAMP ON/OFF, RESET,
INTERNAL PROGRAMS
0 - 19 COLOR CHANGE NORMAL
20 - 39 COLOR CHANGE TO ANY POSITION
40 - 59 LAMP ON
60 - 79 LAMP OFF
80 - 99 ALL MOTOR RESET
100 - 119 INTERNAL PROGRAM 1
120 - 139 INTERNAL PROGRAM 2
140 - 159 INTERNAL PROGRAM 3
160 - 179 INTERNAL PROGRAM 4
180 - 199 INTERNAL PROGRAM 5
200 - 219 INTERNAL PROGRAM 6
220 - 239 INTERNAL PROGRAM 7
240 - 255 SOUND ACTIVE
Accu Spot Pro Gobo Replacement
Caution! Never open the unit when in use. Always disconnect
the main power before attempting to change the gobos.
1. Remove the bottom half of the moving head to access the
gobo wheels.
2. First, Remove the front lens plate by unscrewing the 3 phil-
lips screws. After, unscrew the four phillips screws that hold
the bottom half of the head shell in place. There are two
screws located in the front and two in the rear
3. When you remove the shell you will be able to access the
gobo wheels. Turn your desired gobo wheel with your hand
until you come across the gobo you would like to change.
4. Static Gobo Wheel: With your finger push the gobo out
towards the back and then slide the gobo up and out of the
wheel.
Remove the retainer ring from the gobo frame and remove
the gobo. Insert your new gobo into the frame and replace
retainer ring. Slide the new gobo into place and reassemble
the shell.
Note: Remove the retainer ring using your finger nail or flat
head screwdriver.
Rotating Gobo Wheel: Remove the retainer ring and push the
gobo out, towards the front of the fixture. Insert your new
gobo and replace the retainer ring.
5. Change the gobo by sliding the new gobo into place and
reassemble the shell.
