5-Pin XLR DMX Connectors.

Some manufactures use 5-pin XLR

connectors for DATA transmission in place of 3-pin. 5-pin XLR xtures

may be implemented in a 3-pin XLR DMX line. When inserting stan-

dard 5-pin XLR connectors in to a 3-pin line a cable adaptor must be

used, these adaptors are readily available at most electric stores. The

chart below details a proper cable conversion.

Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)

Pin 1

Pin 5 - Do Not Use

Pin 4 - Do Not Use

Pin 3

Pin 2

Pin 1

Pin 3

Pin 2

Not Used

Data True (+ signal)

Data Compliment (- signal)

Ground/Shield

3-Pin XLR to 5-Pin XLR Conversion

Accu Color 250™ Set Up Accu Color 250™ System Menu

American DJ® - www.americandj.com - Accu Color 250™ Instruction Manual Page 14American DJ® - www.americandj.com - Accu Color 250™ Instruction Manual Page 13

ADDR

AXXX A001

Indicate the staring DMX address

A001 also is the setting for slave

TEST

T-01~T-XX

Automatically test the function

RUN

MSTR/ALON

Runs fixture as “master” or “alone” for auto

AUDI

MSTR/ALON

Runs fixture as “master” or “alone” for audio

PLAY

AUTO

OFF/ RUN / AUDI

Runs fixture for no DMX

ALL

Reset all motors and returns fixture to home

COLR

Reset only motors for colors

RESE

SHTR

Reset only motors for shutter and/or dimmer

LIFE

0000~9999

Displays the total fixture running time

LAMP

0000~9999

Displays a lamps running time

TIME

CLMP

Clear lamp running time

MIC

M-XX

Mic Sensitivity

VALU

D–XX D-00 (DXXX)

Display the DMX512 value of each channel

D ON

ON/OFF

Display turn off after 2mins

DISP

FLIP

ON/OFF

This function will reverse the display 180

RDMX

ON/OFF

Change DMX address via external controller

SPOT

ON/OFF

Lamp optimization

DFSE

ON/OFF

Resets all the fixture functions to default

VER

V1.0~V9.9

Software version

CODE

CXXX

Fixture code *code is “C050”

SPEC

ADJU

CH01~CH30

XXXX(-128~127)

Motor Calibration

STEP

S–01 ~S–48

Set the amount of your program

C–01~C–30

0 1 XX(00~FFH)

3 0 XX(00~FFH)

Edit the channels of each scene

TIME

T XXX(001~999)

Time for each scene

SCXX

CEDT

ON/OFF

Edit program via controller

REC.

RE.XX

Auto Save

EDIT

RUN

ON/OFF

Program test
