©American Audio® - www.americanaudio.us - 10MXR Instruction Manual Page 15
10MXR MIDI TABLE
MXR MIDI interface definition
NOTE: all MIDI messages use channel 1 or channel 2, Directions OUT and IN are relative to the Mixer
NOTE: all MIDI messages use channel 1 or channel 2, Directions OUT and IN are relative to the Mixer
NOTE: all MIDI messages use channel 1 or channel 2, Directions OUT and IN are relative to the Mixer
NOTE: all MIDI messages use channel 1 or channel 2, Directions OUT and IN are relative to the Mixer
Control number is in decimal format
Control number is in decimal format
All rotary VRs start at the minimum in the leftmost position and increase to the maximum when turned clockwise
All rotary VRs start at the minimum in the leftmost position and increase to the maximum when turned clockwise
All rotary VRs start at the minimum in the leftmost position and increase to the maximum when turned clockwise
All rotary VRs start at the minimum in the leftmost position and increase to the maximum when turned clockwise
For 10", 14", 19", "Y" indicates function is used, "N" indicates that it it not used
For 10", 14", 19", "Y" indicates function is used, "N" indicates that it it not used
For 10", 14", 19", "Y" indicates function is used, "N" indicates that it it not used
For 10", 14", 19", "Y" indicates function is used, "N" indicates that it it not used
Description
Control type MIDI Values Remarks (SHIFT)
Microphone
MIC GAIN
Rotary VR NA
MIC 1 TREBLE
Rotary VR 21 00H min to 7FH max Control change B0H (B1H)
MIC 1 BASS
Rotary VR 22 00H min to 7FH max Control change B0H (B1H)
MIC 1 ON/OFF
Button / LED 76 / 76 00H = released, 7FH = pressed note on 90H (91H)
MIXER
MIDILOG 1 GAIN
Rotary VR 0 00H min to 7FH max Control change B0H (B1H)
USB / ANALOG 1
Toggle Switch 89 00H = USB, 7FH = ANALOG note on 90H (91H)
MIDILOG 1 TREBLE
Rotary VR 1 00H min to 7FH max Control change B0H (B1H)
MIDILOG 1 MID
Rotary VR 2 00H min to 7FH max Control change B0H (B1H)
MIDILOG 1 BASS
Rotary VR 3 00H min to 7FH max Control change B0H (B1H)
MIDILOG 1 LINE
Rotary VR 4 00H min bottom to 7FH max top Control change B0H (B1H)
MIDILOG 2 GAIN
Rotary VR 5 00H min to 7FH max Control change B0H (B1H)
USB / ANALOG 2
Toggle Switch 6 00H = USB, 7FH = ANALOG note on 90H (91H)
MIDILOG 2 TREBLE
Rotary VR 6 00H min to 7FH max Control change B0H (B1H)
MIDILOG 2 MID
Rotary VR 7 00H min to 7FH max Control change B0H (B1H)
MIDILOG 2 BASS
Rotary VR 8 00H min to 7FH max Control change B0H (B1H)
MIDILOG 2 LINE
Rotary VR 9 00H min bottom to 7FH max top Control change B0H (B1H)
CROSSFADER
Rotary VR 31 00H min left to 7FH max right Control change B0H (B1H)
CROSSFADER CURVE
Rotary VR 33 00H min to 7FH max Control change B0H (B1H)
NORMAL / REVERSE XFADE
Toggle Switch 78 00H = NORMAL, 7FH = REVERSE note on 90H (91H)
MASTER
Rotary VR 28 00H min to 7FH max Control change B0H (B1H)
BOOTH
Rotary VR 30 00H min to 7FH max Control change B0H (B1H)
CUE MIX
Rotary VR 34 00H min (cue/CH1) to 7FH max (master/CH2) Control change B0H (B1H)
CUE GAIN
Rotary VR 35 00H min to 7FH max Control change B0H (B1H)
Filter
LPF/HPF CH1
Rotary VR 37 00H min to 7FH max Control change B0H (B1H)
LPF/HPF CH2
Rotary VR 39 00H min to 7FH max Control change B0H (B1H)
LPF/HPF MIDILOG 1 Push
Button / LED 22 / 22 00H = released, 7FH = pressed note on 90H (91H)
LPF/HPF MIDILOG 2 Push
Button / LED 24 / 24 00H = released, 7FH = pressed note on 90H (91H)
CENTER BUTTONS
LOAD A
Button / LED 101 00H = released, 7FH = pressed note on 90H (91H)
LOAD B
Button / LED 102 00H = released, 7FH = pressed note on 90H (91H)
LEFT navigate
Button 103 00H = released, 7FH = pressed note on 90H (91H)
RIGHT navigate
Button 104 00H = released, 7FH = pressed note on 90H (91H)
UP navigate
Button 105 00H = released, 7FH = pressed note on 90H (91H)
DOWN navigate
Button 106 00H = released, 7FH = pressed note on 90H (91H)
Center encoder Push
Button 107 00H = released, 7FH = pressed note on 90H (91H)
Center Encoder
Rotary Encoder 52 3FH=CCW, 41H = CW Control change B0H (B1H)
Shift
Button / LED 109 / 111 00H = released, 7FH = pressed note on 90H
Left Buttons
CUE Left
Button / LED 12 /12 00H = released, 7FH = pressed note on 90H (91H)
PLAY/PAUSE >|| Left
Button / LED 13 / 13 00H = released, 7FH = pressed note on 90H (91H)
HOT START 1 Left
Button / LED 18 /18 00H = released, 7FH = pressed note on 90H (91H)
HOT START 2 Left
Button / LED 19 / 19 00H = released, 7FH = pressed note on 90H (91H)
SYNC Left
Button / LED 21 / 21 00H = released, 7FH = pressed note on 90H (91H)
RIGHT BUTTONS
CUE Right
Button / LED 46 / 46 00H = released, 7FH = pressed note on 90H (91H)
PLAY/PAUSE >|| Right
Button / LED 47 / 47 00H = released, 7FH = pressed note on 90H (91H)
HOT START 1 Right
Button / LED 52 / 52 00H = released, 7FH = pressed note on 90H (91H)
HOT START 2 Right
Button / LED 53 / 53 00H = released, 7FH = pressed note on 90H (91H)
SYNC Right
Button / LED 54 /54 00H = released, 7FH = pressed note on 90H (91H)
