10
User’s manual
EN
PREPARATION AND MARKING THE BOUNDARIES OF THE WORK AREAS
preparation of the lawn to be mowed
1. Make sure that the lawn to mow is even and does not contain holes, stones or other obstacles. Otherwise, prepare the lawn
by lling in any holes and removing any obstacles. If some obstacles cannot be removed, it is necessary to properly dene
and protect the interested areas.
2. Check that all the areas of the lawn do not exceed the allowable slopes (see “Technical Specications”).
The sensors, which recognise the presence of the grassy surface, allow the robot to move freely inside the lawn. The lawn must
be suitably checked and adjusted so that the robot has enough space for recognising when there is no grass. Carefully follow
the below points for the correct and safe use of the robot.
OK
WALL
higher than
9 cm. / 3,5 "
HEDGING
SMALL ARCHES
PAVING
wider than 35 cm. / 13.8 "
Minimum width of 5 cm / 1.9 in.
with drop-off sensor on and step
depth of at least 5 cm / 1.9 in.
Types of boundaries/protections that can be used for correctly dening the limits of the robot’s work area.
Pavement
With the drop-off sensor on, the robot requires a curb of at
least 5 cm and a step depth of at least 5 cm. Curbs less than 5
cm wide or steps less than 5 cm deep must be protected with
additional pavement, or alternatively, by placing arches in the
ground, as shown in the gure, so that the robot can run into
them and change direction.
If the robot is not equipped with a drop-off sensor or if the
sensor is off, a pavement of at least 35 cm is needed for it to
stop safely and change direction.
> 35 cm (13.8 ")
< 5 cm
< 5 cm
> 5 cm
> 5 cm
Wall
Perimeter wall, which denes the boundary of the work area at
a height above 9 cm. (3.54 "). If the walls are shorter, protect the
area with arches or adequate paving.
minimum high
9 cm. (3,50 ")
OK
