Note: Ensure the lighting fixture is turned off before installing/removing the Spotlight SE.
Installation Instructions
Installing:
1.
2.
3.
4.
Removing:
1.
2.
3.
Installing Removing
1.
2.
3.
Ensure the Lens Locking Knob is loose so a len can be inserted.
Align the Aligning Pin with the V-shaped cutout on the Spotlight SE, and slide in the lens
slightly.
Rotate the lens clockwise until it stops.
The lens is now engaged. Slide it into a desired position and tighten the Lens Locking Knob
to fix it in place.
Loosen the Lens Locking Knob while holding the lens in its position.
Start pulling the lens out of the Spotlight SE until it comes to a stop.
Rotate the lens counterclockwise until the V-shped cutout is aligned with the Aligning Pin
and pull out the lens completely.
1.
2.
4.
3.
Before installing the Spotlight SE on a lamp head, ensure the lens on the Spotlight SE is tightened
securely (if there is one installed).
1.
2.
Depending on the output intensity of the light and duration of its operation, the Gobo
Holder and the M size gobo may be too hot to be stored in the case immediately
