8
USING YOUR AIR CONDITIONER
Turning the Air Conditoner ON or OFF
Press POWER to turn the air conditoner on or off.
IMPORTANT:
■ If you turn off the air conditioner, wait at least
3 minutes before turning it back on. This prevents
the air conditioner from blowing a fuse or tripping a
circuit breaker.
■ The recommended operating temperature range is between
44°F (7°C) and 95°F (35°C). Operating the air conditioner
above or below this range may cause the the inside
evaporator coil to freeze up, and the air conditioner will not
operate properly.
NOTE: In the event of a power failure, your air conditioner will
operate at the previous settings when the power is restored.
Display
During normal operation, display will
show the current room temperature
and the mode and settings. When the
UP or DOWN button is pressed, the
unit will display the set temperature or
delay time.
Selecting the Mode
The Mode button has three settings:
■ Cool
■ Dehumidify
■ Fan
Press the MODE button until the indicator light below the desired
setting is lit.
Cooling (COOL) Mode
During Cooling mode, the air conditioner cools air from
the room and vents hot air to the outdoors through
the vent hose(s). Adjust fan speed and the temperature setting
to fit your desired comfort level. Temperature setting range is 60°
F–86°F (16°C–30°C).
IMPORT
ANT: The vent hose(s) must exhaust to the outdoors
when using Cooling mode.
Dehumidify (Dry) Mode
Air is dehumidied as it passes through the unit,
without being in full cooling mode. The fan speed is set
automatically to LOW and cannot be adjusted .
IMPORTANT: For best results, the continuous drain hose should
be connected.
Fan (FAN) Mode
In this mode, only the fan will run. Air is circulated through the
room with no cooling.
NOTE: The air conditioner does not need to be vented to the
outdoors in Fan mode.
Selecting the Fan Speed
The Fan has 3 speed settings:
■ Low
■ Medium
■ High
Press the FAN button until the desired setting is selected.
Adjusting the Temperature
Press the UP or DOWN buttons to
adjust the set temperature up or down
in 1° increments. Temperature setting
range is 60°F–86°F (16°C–30°C). After
10 seconds, the display will return to the current room
temperature.
NOTE: Temperature may only be adjusted in Cooling mode.
When in TIMER mode, pressing the UP or DOWN buttons will
adjust the delay time for the air condtioner to shut off or turn on.
Appearance may vary.
