- 4 - ALTV1224C4 Installation Guide

Enclosure Dimensions:

13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm)

1.40”

(35.6mm)

1.40”

(35.6mm)

1.40”

(35.6mm)

4.85” (123.2mm)

4.85” (123.2mm)

3.25” (82.6mm)

0.75”

(19.1mm)

0.75”

(19.1mm)

11.0” (279.4mm)

12.5” (317.5mm)

1.20”

(30.5mm)

1.20”

(30.5mm)

0.9375” (23.8mm)

0.9375” (23.8mm)

5.10” (129.5mm)

1.40”

(35.6mm)

5.10” (129.5mm)

6.5625” (166.7mm)

3.25” (82.6mm)3.25” (82.6mm)

3.25” (82.6mm)

10.5” (266.7mm)

1.0”

(25.4mm)

1.0”

(25.4mm)

1.0” (25.4mm)

13.0” (330.2mm)

5.10” (129.5mm)

1.20”

(30.5mm)

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user

to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may be of

sufficient magnitude to constitute an electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor-

tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.

CAUTION: To reduce the risk of electric shock do not open enclosure.

There are no user serviceable parts inside.

Refer servicing to qualified service personnel.

Altronix is not responsible for any typographical errors.

––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––

140 58th Street, Brooklyn, New York 11220 USA | 718-567-8181 | fax: 718-567-9056

website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty

IIALTV1224C4 J26U
