17
General
System Type 2-way active ported loudspeaker
Drivers
L
ow-Frequency: 12.0” (305 mm) driver, 2.0” (51 mm) voice coil
H
igh-Frequency: 1.0” (25 mm) titanium-diaphragm compression
driver, 1.0” (25 mm) voice coil
Amplifier 700 watts (peak), Class D power
Horn Coverage 90º horizontal x 60º vertical (nominal)
Frequency Response 70 Hz – 20 kHz (-3 dB)
Max SPL 120 dB @ 1 m
Equalization Contour switch with low- and high-frequency +3 dB boost
Connectors
(1) XLR/TRS input (Line/Mic)
(1) XLR/TRS output
(1) IEC power cable input
Controls
Power switch, volume control knob, contour switch, ground-lift
switch
Indicators (2) power LEDs (1 front panel, 1 rear panel), clip limiter LED
Bluetooth
V
ersion: 5.0
P
rofiles: A2DP, AVRCP
Power
C
onnection: IEC
V
oltage: 100–120V~, 50/60 Hz; 220–240V~, 50/60 Hz
F
use: 100-120V T6.3AL AC250V; 220-240V T3.15AL AC250V
C
onsumption: 350W
Protection Thermal, overload analog limiter/compressor
Enclosure
Injection-molded polypropylene, multi-angle for main or monitor
applications, metal grille, rubber feet, 2 handles (both sides)
Mounting/Installation Standard 36 mm pole socket, wedge monitor
Dimensions
(height x width x depth)
23.7” x 15.0” x 13.5”
602 x 381 x 343 mm
Weight
29.3 lb
13.3 kg
