11
TX18S
Line Inputs CH1/CH2
Connector XLR/TRS combo input connector (line is TRS only)
Dynamic Range 108 dB (A-weighted)
THD +N (%, -1 dBFS input) <0.01%
Maximum Input Level +16 dBu
Gain Range 24 dB
Frequency Response 20 Hz – 20 kHz (+/- 0.1 dB)
Input Impedance
20k
CH1/CH2 Thru
Connector XLR output connector
Frequency Response 20 Hz – 20 kHz (+/- 0.1 dB)
Output Level (for 0.5% THD) Fixed +10 dBu
Input Impedance (unbalanced)
100
General
Output Power 900 watts (peak), Class D power
Frequency Response 36 Hz – 115 Hz (-3dB)
Maximum SPL 126 dB
Low Frequency Driver 18.0” (457 mm) woofer / 3.0” (76 mm) voice coil
User Low Pass Filter 80 Hz, 100 Hz, 120 Hz (24 dB per octave)
Low Frequency Extension HPF 50 Hz (default) and 45Hz (extension on)
Polarity 180º phase inversion
Enclosure Internally braced MDF cabinet, splatter spray finish, metal grille
Mounting 36 mm pole socket
Power
C
onnection: Standard IEC cable
I
nput Voltage: 100-120, 50/60 Hz; 220-240 VAC 50/60 Hz
C
onsumption: 500 W
F
use: 110-120V T6.3 AL AC250V; 220-240V T3.15AL AC250V
Dimensions (height x width x depth) 23.0” x 23.0” x 23.0” / 585 x 585 x 585 mm
Weight 87.7 lbs / 39.8 kg
Specifications are subject to change without notice.
Bluetooth and wireless reception and range are aected by walls, obstructions, and movement. For optimal
performance, place the product in the center of the room so it is unobstructed by walls, furniture, etc. Battery life may
vary based on temperature, age, and volume usage of product.
