INSTALLATION
Vect or H™ Seri es ▪ Ope rato r’s Man ual ▪ MN-462 95 ▪ R ev 1 ▪ 1 1/19
35
Wire sizes 60335-1 IEC:2010
Position the oven
To position the oven, do the following.
Step Action
1. Make sure that:
▪ The location where the oven is being installed is rated to support the
weight of the oven,
▪ The oven is within five feet of the appropriate electrical outlet,
▪ You follow the oven clearance guidelines.
2. Move the oven to the installation location and onto the final resting surface.
The oven is now correctly positioned.
Continued on next page
Rated current of appliance
A
Nominal cross-sectional area
mm
2
>0.2 – ≤3
>3 – ≤0
>6 – ≤10
>10 – ≤16
>16 – ≤25
>25 – ≤32
>32 – ≤40
>40 – ≤63
0.5
0.75
1.0
1.5
2.5
4
6
10
VMC-DIM-007498
2.0"
51mm
2.0"
51mm
2.0"
51mm
2.0"
51mm
