INSTALLATION
Vect or H™ Seri es ▪ Ope rato r’s Man ual ▪ MN-462 95 ▪ R ev 1 ▪ 1 1/19
17
INSTALLATION
Dimension Drawings
VMC-H2: 37-1/2" (953mm)
VMC-H2H: 39-1/2" (1003mm)
VMC-H2: 34-11/16" (882mm)
VMC-H2H: 36-11/16" (932mm)
VMC-H3: 37-1/2" (953mm)
VMC-H3H: 39-1/2" (1003mm)
VMC-H4: 37-1/2" (953mm)
VMC-H4H: 39-1/2" (1003mm)
VMC-H3: 34-11/16" (882mm)
VMC-H3H: 36-11/16" (932mm)
VMC-H4: 34-11/16" (882mm)
VMC-H4H: 36-11/16" (932mm)
16-3/8"
(416mm)
16-3/8"
(416mm)
16-3/8"
(416mm)
23-5/16" (593mm)
27-1/8" (688mm)
27-1/8" (688mm)
23-5/16" (593mm)
27-1/8" (688mm)
21-1/2"
(546mm)
21-1/2" (546mm)
23-5/16" (593mm)
21-1/2"
(546mm)
H2, H3, H4: 54-3/8" (1382mm)
H2H, H3H, H4H: 56-3/8" (1432mm)
19-9/16"
(498mm)
22-5/8” (575mm)
25-5/8" (650mm)
29-5/8" (752mm)
41-1/4" (1048mm)
43-5/8" (1108mm)
39-5/8" (1006mm)
36-5/8” (931mm)
32-5/8" (827mm)
36-5/8" (929mm)
29-13/16" (757mm)
4" (102mm)
4" (102mm)
4" (102mm)
3-38" (85mm)
3-3/4"
(94 mm)
14-11/16"
(373mm)
4-5/16"
(109mm)
H2 - H3 - H4
19" (483 mm)
H2H - H3H - H4H
21" (533 mm)
6" (152mm)
4" (102mm)
4-1/4" (108mm)
4-15/16" (125mm)
21"
(535mm)
21"
(535mm)
21"
(535mm)
electrical connection
electrical connection
electrical connection
electrical connection
