MN-29506 (REV. 6) 11/15 • HFT2/HFT2SYS SERIES MERCHANDISERS • 23
SERVICE
SERVICE PARTS LIST - BASE
MODEL > HFT2-300 HFT2-400
HFT2-500
ITEM DESCRIPTION PART NO. QTY PART NO. QTY PART NO. QTY
1 CORD COVER PLATE 1006591 2 1006591 2 1006591 2
2 BASE STAND TOP PANEL 1006995 1 1012228 1 1008348 1
3 BASE SUPPORT SPOT 5005235 1 5013540 1 5007460 1
4 BASE STIFFENER, SPOT 5013483 2 5013541 2 5012923 2
5 T-BLOCK BK-3019 1 BK-3019 1 BK-3019 1
6*
CORDSET 208-240V
230V
CD-3588
CD-3922
1
1
CD-3304
CD-33490
1
1
CD-3304
CD-33490
1
1
7 CASTER, RIGID 5" (127mm) CS-2025 2 CS-2025 2 CS-2025 2
8 CASTER, SWIVEL 5" (127mm) WITH BRAKE CS-2026 2 CS-2026 2 CS-2026 2
9 PLUG, 7/8" HOLE PG-3559 1 PG-3559 1 PG-3559 1
10 RIVET, BLIND, #44, STNLS RI-2100 72 RI-2100 64 RI-2100 72
11* 3/8-16 x 1-1/2" HEX CAP SC-22553 6 SC-22553 6 SC-22553 6
12 5/16-18 x 5/8" SERR. HEX HD SCREW SC-2351 16 SC-2351 16 SC-2351 16
13 6-32 x 1-1/4" ROUND HD SC-2365 2 SC-2365 2 SC-2365 2
14 8-32 x 1/2" PHIL SCREW SC-2425 8 SC-2425 8 SC-2425 8
15* 3/8" ID 7/8" OD S/S FLAT WASHER WS-23991 6 WS-23991 6 WS-23991 6
*NOT SHOWN
DANGER
Ensure power source matches
voltage identified on appliance rating
tag. The rating tag provides essential
technical information required for any
appliance installation, maintenance
or repairs. Do not remove, damage or
modify the rating tag.
This section is provided for the
assistance of qualified and trained
service technicians only and is not
intended for use by untrained or
unauthorized service personnel.
Failure to observe this precaution
may void the warranty.
CABLE HEATING REPLACEMENT SERVICE KITS HFT2-300 HFT2-400 HFT2-500
KIT NUMBER > 4880 4881 5 4880
SERVICE KIT INCLUDES:
CB-3045 CABLE HEATING ELEMENT 132 ft 144 ft 120 ft
CR-3226 RING CONNECTOR 8 12 8
IN-3488 INSULATION CORNER 8 ft 8 ft 8 ft
BU-3105 SHOULDER BUSHING 8 12 8
BU-3106 CUP BUSHING 8 12 8
SL-3063 INSULATING SLEEVE 8 12 8
TA-3540 HIGH TEMP ELECTRICAL TAPE 1 roll 1 roll 1 roll
ST-2439 10.32 STUD 8 12 8
NU-2215 HEX NUT 32 24 32
CALIBRATION PROCEDURES
Every unit is calibrated at the factory. Only a qualified
service technician should calibrate the unit in the field
if necessary.
SHOCK RISK WARNING: Unit must be disconnected
from power source before making adjustments or
calibrating switch.
TOOLS REQUIRED: 2mm allen (hex) wrench
CALIBRATION
