MN-29506 (REV. 6) 11/15 • HFT2/HFT2SYS SERIES MERCHANDISERS • 21
MODEL > HFT2-300 HFT2-400
HFT2-500
ITEM DESCRIPTION PART NO. QTY PART NO. QTY PART NO. QTY
1 INNER TOP LIGHT END 1007098 2 1007098 2 1007098 2
2 TERMINAL BRACKET HOLDER 1007507 1 1007507 1 1007507 1
3 RECEPTACLE LOCK 1008952 12 1008952 16 1008952 16
4 CONTROL ATTACHMENT PLATE 1012113 1 1012113 2 1012113 2
5 END LEXAN POSITION CLIP 1012185 4 1012185 4 1012185 4
6 BOTTOM COVER PANEL 1007110 1 1012222 1 1008268 1
7 INNER TOP SIDE 1007080 1 1012223 1 1008327 1
8 INNER TOP CONTROL SIDE 1012196 1 1012224 1 1011896 1
9 INNER LIGHT PANEL 1008316 1 1012226 1 1008330 1
10 WELL ENCLOSURE, SPOT 5013467 1 5013526 1 5012935 1
11* CONTACTOR BRACKET 1012353 1 1012353 1 1012353 1
12 INNER TOP SPOT 5005806 1 5013538 1 5007446 1
13 T-BLOCK BK-3019 2 BK-3019 2 BK-3019 2
14 BUSHING, 1" HOLE BU-33619 4 BU-33619 4 BU-33619 5
15* HINGE, UPRIGHT SUPPORT HG-27333 2 HG-27333 2 HG-27333 2
16 INSULATION, BOARD, 5.875 x 21.670, 1/2" IN-2003 2 IN-2003 2 IN-2003 2
17 INSULATION, BOARD, 6 x 50.125, 1/2" IN-2003 2 IN-2003 2 IN-2003 2
18 INSULATION, FLUFF IN-22364 1 IN-22364 1 IN-22364 1
19 KNOB, THERMOSTAT KN-26568 1 KN-26568 2 KN-26568 2
20 PILOT LIGHT, WHITE LI-3951 1 LI-3951 2 LI-3951 2
21 LAMP, FLOOD LP-37051 6 LP-37051 8 LP-37051 8
22 PANEL OVERLAY PE-29421 1 PE-29421 2 PE-29421 2
23 RIVET, BLIND #44, STNLS RI-2100 12 RI-2100 20 RI-2100 12
24 RECEPTACLE, SNAP IN RP-3955 6 RP-3955 8 RP-3955 8
25 SCREW, GROUND 10-32 x 1/4 PAN HD SC-2190 2 SC-2190 2 SC-2190 2
26 SCREW, 6-32 x 1-1/4 ROUND HD SC-2365 4 SC-2365 4 SC-2365 4
27 SCREW, 8-32 x 1/4 PHIL SC-2459 68 SC-2459 74 SC-2459 80
28* SCREW, 10-32 x 1/4 PAN HEAD SC-26791 12 SC-26791 12 SC-26791 12
29 SWITCH, 20A, 250V, TOGGLE SWITCH SW-3528 1 SW-3528 1 SW-3528 1
30 SWITCH, RUBBER BOOT W/ NUT SW-3905 1 SW-3905 1 SW-3905 1
31 THERMOSTAT, 240V, 13A TT-34981 1 TT-34981 2 TT-34981 2
32* CONTACTOR 208/240V E POLE 25 AMP CN-3052 1 CN-3052 1 CN-3052 1
33* 3/4" WHITE SNAP BUSHING BU-3008 2 BU-3008 2 BU-3008 2
34 WELL CABLE ASSEMBLY 5013477 1 5013527 1 5013476 1
*NOT SHOWN
SERVICE
SERVICE PARTS LIST - CORE UNIT
WARNING
To prevent SERIOUS INJURY,
DEATH, OR PROPERTY DAMAGE,
ALWAYS disconnect unit from power
source before cleaning or servicing.
