INSTALLATION
Converge® ▪ Operator’s Manual ▪ MN-47239 ▪ Rev 4 ▪ 4/24
22
7-1/16"
180mm
BACK WALL
CLEARANCE
7-3/4"
5-7/8"
197mm
149mm
SEISMIC LEGS
6-5/16"
4-1/16"
160mm
103mm
39-11/16"
1008mm
19-7/16"
493mm
CAVITY HEIGHT
14-3/8"
366mm
CAVITY WIDTH
5-7/8"
149mm
MOBILE BASE
40-1/4"
1023mm
37-9/16"
955mm
34-3/4"
883mm
24-7/16"
621mm
4-7/16"
112mm
A
ELECTRICAL
CONNECTION
60-1/8"
1527mm
3-3/4"
95mm
2-11/16"
68mm
11-1/2"
292mm
14-5/16"
364mm
2-9/16"
66mm
16-1/4"
412mm
7-15/16"
201mm
2-1/4"
57mm
DETAIL A
Y1 STEAM INJECTION
OVEN DRAIN
MANUAL DRAIN
34-11/16"
22"
10-7/8"
882mm
277mm
18-3/8"
a
b
c
d
a
c
d
b
Chamber width
Chamber depth
Chamber height
Chamber height with wire shelf
4-3/4
"
(121mm)
4-3/16
"
(106mm)
14-3/8
"
(366mm)
21-1/8
"
(537mm)
Y2 CONDENSATE/
RINSE/WASH
WATER
Y5 HOSE REEL
559mm
467mm
