serVIce
AR-6G Rotisserie Operation & Care Manual • 29
Part numbers and drawings are subject to change without notice.
AR-6G Rotisserie Operation & Care Manual • 29
Item part no. DescrIptIon Qty Item part no. DescrIptIon Qty
1 5005242 BOTTOM TOP PLATE SPOT 1 23 5012971 LOWER FRONT PANEL SPOT (S/S) 1
2 WS-22094 WASHER, 1/4", FLAT, 5/8 OD 18-8 SS 67 PE-29429 LOWER FRONT PANEL SPOT (BLK) 1
3 TA-28540 TAPE HIGH TEMP GASKET,
9' (2743mm) 1 24 1006508 BOTTOM SIDE PANEL, LEFT (S/S) 1
4 1006515 BOTTOM ACCESS COVER 1 PE-27609 BOTTOM SIDE PANEL, LEFT (BLK) 1
5 SC-22729 SCREW 1/4-20 X 1/2" HEX HEAD 74 25 TR-34416 2 HOUR TIMER W/ BUZZER 1
6 5009176 ELECTRICAL PANEL 1 26 HR-27630 HANGER, U BOLT 1
7 SC-28434 SCREW 10-32 X 3/8" HEX HEAD 2 27 LA-34435 LABEL, FUSE WARNING 1
8 CD-34094 CORD 16/3 SJT, NEMA 5-15P,
10' (3048mm) 1 28 5005252 GAS PLUMBING ASSEMBLY 1
9 BU-3964 BUSHING, STRAIGHT, STRAIN RELIEF 1 29 NU-2437 NUT, 1/4-20 HEX S/S 19
10 1006511 BOTTOM COVER BACK COVER 1 30 1008936 SUPPORT BRACKET 6
11 1006509 BOTTOM SIDE PANEL, RIGHT (S/S) 1 31 SW-34985 SWITCH, SPARK 3
PE-27610 BOTTOM SIDE PANEL, RIGHT (BLK) 1 5012978*
SPARK SWITCH SERVICE KIT
(for units prior to 2011, contact service with serial #)
1
12 NU-24613 1/4-20 INSERT NUT 38 32 NU-2296* NUT, HEX #8-32 6
13 5008607 CASTER WELD WITH LH BRAKE 2 33 SC-24751* SCREW 8-32 X 1/4" HEX HEAD 6
14 5008609 CASTER WELD WITH NO BRAKE 4 34 CR-33250* CONNECTOR, 3/16" DUAL SPADE 1
15 5005239 BOTTOM PLATE SPOT & WELD 1 35 CR-34559* CONNECTOR 2
16 KN-28061 KNOB, GAS SHUTOFF 3 36 CR-3849* CONNECTOR, DUAL SPADE, 1/4" 5
17 SC-2191 SCREW, HEX HEAD, 5/16-18 X 1" LONG 24 37 BK-33364* T-BLOCK, MODULAR 2
18 WS-2867 WASHER, LOCK, 5/16 DIA. 24 38 FU-3772* FUSE HOLDER, DUAL, 15A, CLASS G 1
19 SW-34101 SWITCH, FAN HI/LOW 5 39 FU-3775* 15A CLASS G FUSE 2
20 SW-34430 SWITCH, EMERGENCY STOP 1 40 TN-33460* TRANSFORMER, STEP DOWN 1
21 KN-34103 KNOB, INDICATOR 1 41 BK-3019* T-BLOCK 1
22 PE-28009 PANEL OVERLAY AR-6G 1 42 5007975* WIRE SET 120V 1
bottom assembly
* NOT SHOWN
