holding c a b i n e t s • i n s t a l l a t i o n /o p e r a t i o n /s e r v i c e manual - pg. 4
28-9/16" (726mm)
56-7/8" (1444mm)
34-7/8" (886mm)
Pass-Through
Option
Electrical
Connection
53-15/16" (1369mm)
78-7/8" (2003mm)
26-7/16" (670mm)
23-5/8" (600mm)
26-5/8" (676mm)
25-5/8" (651mm)
24-1/8" (612mm)
33-13/16" (858mm)
16-15/16"
(429mm)
30-3/8" (771mm)
33-9/16" (852mm)
with 3-1/2" (89mm) casters*
5-5/16" (134mm)
*31-7/8" (809mm) - with optional 2-1/2" (64mm) casters
*35-1/4
" (895mm) - with optional 5" (127mm) casters
*33-15/16
" (861mm) - with optional 6" (152mm) legs
31-3/8" (797mm)
Electrical
Connection
Pass-Through
Option
Cord Length:
120V - 5' (1524mm)
208-240V - 8' (2438mm)
230V - 8' (2438mm)
Model 750-S
INSTALLATION
WEIGHTS AND CAPACITIES
Model 500-S
Electrical
Connection
Shown with
optional bumper
21" (532mm)
58-11/16" (1490mm)
41-5/16" (1049mm)
29-7/8" (758mm)
44-1/4" (1124mm)
18-3/4" (477mm)
18" (458mm)
33-9/16" (852mm)
with 3-1/2" (89mm) casters*
5-5/16" (134mm)
16" (406mm)
19" (483mm)
28-13/16" (731mm)
14-3/8"
(365mm)
19-1/8"
(485mm)
30-7/16" (772mm)
*31-7/8" (809mm) - with optional 2-1/2" (64mm) casters
*35-1/4" (895mm) - with optional 5" (127mm) casters
*33-15/16" (861mm) - with optional 6" (152mm) legs
Pass-Through
Option
Electrical
Connection
26-3/8" (670mm)
Electrical
Connection
Pass-Through
Option
Cord Length:
120V - 5' (1524mm)
208-240V - 8' (2438mm)
230V - 8' (2438mm)
WEIGHT - 500-S
net 94 lb (43kg) est.
ship 175 lb (79kg) est.
carton dimensions: (l x w x h)
35" x 35" x 41" (889mm x 889mm x 1041mm)
WEIGHT - 750-S
net 157 lb (69kg)
ship 228 lb (103kg) est.
carton dimensions: (l x w x h)
35" x 35" x 41" (889mm x 889mm x 1041mm)
PRODUCT\PAN CAPACITY - 500-S
60 lbs (27 kg)
maximum
volume maximum: 50 quarts (47.5 liters)
full-size pans: gastronorm 1/1:
Six (6) 20" x 12" x 2-1/2" 530mm x 325mm x 65mm
Three (3) 20" x 12" x 4" 530mm x 325mm x 100mm
half-size sheet pans:
Eleven (11) 18" x 13" x 1" 457mm x 330mm x 25mm
PRODUCT\PAN CAPACITY - 750-S
120 lbs (54 kg)
maximum
volume maximum: 100 quarts (95 liters)
full-size pans: gastronorm 1/1:
Ten (10) 20" x 12" x 2-1/2" 530mm x 325mm x 65mm
Six (6) 20" x 12" x 4" 530mm x 325mm x 100mm
Four (4) 20" x 12" x 6" 530mm x 325mm x 150mm
full-size sheet pans (on wire shelves only):
Up to Six (6) 18" x 26" x 1" – with addit i onal shelve s
