MN-29423 • Rev 6 • 02/18 • S-Series Hot Food Holding Cabinets 33
Service
Single Compartment - 300-S
Item Description Part No. Qty
1 Top Cover 1012831 1
2 T-Block BK3019 1
3 Breaker Switch Cutout Cover 11133 1
4 Bushing, Straight, Strain Relief BU34898 1
5 Rear Trim 5014525 1
6 Insulation IN2003 1
7 Cordset 120V CD3232 1
230V (CEE 7/7) CD3922 1
230V (CH2-16P) CD36231 1
230V (BS 1363) CD33925 1
8 Hi-Limit Protection Cover 1003936 1
9 Rivet, Blind, #44, S/S RI2100 16
10 Hi-Limit Thermostat TT33476 1
11 Sensor Mounting Bracket 1493 1
12 Block, Sensor BK29606 1
13 Screw, 6-32 x 1/2, NC Phil, Flat SC2254 2
14 Sensor, Oven Temperature PR34494 1
15 Insulation IN22364 1
16 Screw, M5 x 0.8 x 16mm Flat SC22281 16
17 Transport Handle HD2021 4
18 Nut, Hex Insert M5 NU23909 16
19 Outer Casing Spot 5014538 1
20 Hinge Plate, Bottom Right Hand 1012999 1
Le Hand* 1014661 1
21 Screw, 8-32 x 1/4" Trh Phh SC2459 12
22 Handle, Pull, Recessed HD28789 1
23 Door Assembly 5014458 1
24 Door Gasket GS35092 1
25 Door Latch 1013803 1
26 Door Latch Receiver 1013809 1
27 Screw, M3 x 0.5 x 6mm Pan SC22266 2
28 Stud, Shoulder, Short, S/S ST2546 1
29 Panel, Overlay PE35188 1
30 Side Racks 1012872 2
31 Control CC34970 1
32 Electric Chassis Spot 5014530 1
33 Switch, Rocker, 125-277V, 20A SW34769 1
34 Switch Cover (230V only) CV38297 1
35 Gaskets, Adhesive,.125 x .375 GS23622 1
36* Probe Cover 1008807 1
37* Bushing, 3/4" Snap BU3008 1
38* Nut, 6-32 Hex, S/S NU2361 4
39* Screw, 10-32 x 1/4 Pan Hd Ground SC2190 1
40* Screws, M4-0.7 x 6mm Phil SC22271 2
41* Screw, HHCS M6 x 20, w/No Mkgs SC22924 1
42* Screw, 6-32 x 1-1/4" Round Hd SC2365 2
43* Screw, M6 x 1.0 x 10 Pan SC27078 2
44* Shelves SH2107 2
45* Spacer, Snap-In, 7/16", Control SP29392 6
46* Washer, Flat WS22297 2
47* Washer, Split Lock WS22302 2
48* Washer, 6-32, Flat, Nylon WS23148 4
49* Washer, Star Lock WS2467 1
50* Foil Pad Heater, 230V EL29740 1
51* Foil Pad Heater, 120V EL35173 1
*Not shown
