MN-37234 (Rev. 0) 03/15 • Hot Food Drop-In Well • 13
INSTALLATION
ROUGH CUT OPENINGS
MODEL
COUNTER CUTOUT
(W x D)
CONTROL BOX CUTOUT*
(H x W x D)
100-HW/D4 or D6 one full-size
100-HWLF/D4 or D6 one full-size
14-1/4" x 22-1/2"
(363mm x 572mm)
4-1/4" x 5-1/4" x 10-13/16"
(108mm x 133mm x 274mm)
100-HW/D443 or D643 one full & one third-size pan
14-1/4" x 29-1/2"
(363mm x 749mm)
4-1/4" x 5-1/4" x 10-13/16"
(108mm x 133mm x 274mm)
200-HW/D4 or D6 two full-size pans
200-HWLF/D4 or D6 two full-size pans
27" x 22-1/2"
(686mm x 572mm)
4-1/4" x 5-1/4" x 10-13/16"
(108mm x 133mm x 274mm)
200-HW/D443 or D643 two full & two third-size pans
27" x 29-1/2"
(686mm x 749mm)
4-1/4" x 5-1/4" x 10-13/16"
(108mm x 133mm x 274mm)
200-HWI/D4 or D6 two full-size pans
200-HWILF/D4 or D6 two full-size pans
27" x 22-1/2"
(686mm x 572mm)
4-1/4" x 8-3/4" x 10-13/16"
(108mm x 222mm x 274mm)
200-HWI/D443 or D643 two full & two third-size pans
27" x 29-1/2"
(686mm x 749mm)
4-1/4" x 8-3/4" x 10-13/16"
(108mm x 222mm x 274mm)
300-HW/D4 or D6 three full-size pans
300-HWLF/D4 or D6 three full-size pans
40" x 22-1/2"
(1016mm x 572mm)
4-1/4" x 5-1/4" x 10-13/16"
(108mm x 133mm x 274mm)
300-HW/D443 or D643 three full & three third-size pans
40" x 29-1/2"
(1016mm x 749mm)
4-1/4" x 5-1/4" x 10-13/16"
(108mm x 133mm x 274mm)
300-HWI/D4 or D6 three full-size pans
300-HWILF/D4 or D6 three full-size pans
40" x 22-1/2"
(1016mm x 572mm)
4-1/4" x 12-1/4" x 10-13/16"
(108mm x 311mm x 274mm)
300-HWI/D443 or D643 three full & three third-size pans
40" x 29-1/2"
(1016mm x 749mm)
4-1/4" x 12-1/4" x 10-13/16"
(108mm x 311mm x 274mm)
400-HW/D4 or D6 four full-size pans
400-HWLF/D4 or D6 four full-size pans
53-1/8" x 22-1/2"
(1350mm x 572mm)
4-1/4" x 8-3/4" x 10-13/16"
(108mm x 222mm x 274mm)
400-HWI/D4 or D6 four full-size pans
400-HWILF/D4 or D6 four full-size pans
53-1/8" x 22-1/2"
(1350mm x 572mm)
4-1/4" x 15-3/4" x 10-13/16"
(108mm x 400mm x 274mm)
500-HW/D4 or D6 five full-size pans
500-HWLF/D4 or D6 five full-size pans
66-1/4" x 22-1/2"
(1683mm x 572mm)
4-1/4" x 8-3/4" x 10-13/16"
(108mm x 222mm x 274mm)
500-HWI/D4 or D6 five full-size pans
500-HWILF/D4 or D6 five full-size pans
66-1/4" x 22-1/2"
(1683mm x 572mm)
4-1/4" x 19-1/4" x 10-13/16"
(108mm x 489mm x 274mm)
