500-S, 750-S, 1000-S, 1000-UP • INSTALLATION/OPERATION/SERVICE MANUAL • 27.
S E R V I C E
M O D E L > 5 0 0 - S 7 5 0 - S 1 0 0 0 - S 1 0 0 0 - U P
I T E M D E S C R I P T I O N PA R T N O . Q T Y PA R T N O . Q T Y PA RT NO. Q T Y PA RT NO. QTY
1 PAN COVER —— —— —— —— —— —— 1774 2
2 MOISTURE PAN —— —— —— —— —— —— 1775 2
3 VENT PANEL 13115 2 12863 2 12863 2 12863 4
4 VENT SLIDE 13116 2 12864 2 12864 2 12864 4
5 SHIM, HINGE 13675 2 13675 2 13676 2 13676 4
6
SLAB DOOR ASSY.
(INCLUDES VENTS AND GASKET)
55649 1 55648 1 55646 1 55646 2
7 BRACKET, SIDE PANEL 1003649 4 1003649 4 1003649 4 1003649 4
8 BONNET, TOP COVER 1003889 1 1003888 1 1003887 1 1003887 1
9 PANEL, SIDE, STD 1007199 2 1005959 2 1003468 2 1004985 2
PANEL, SIDE, HD 5002725 2 5002726 2 5005612 2 5002788 2
10 OUTER BACK PANEL, STD 1007198 1 1006747 1 1004988 1 1004988 2
OUTER BACK PANEL, HD 1007197 1 1006710 1 1006697 1 1006697 2
11 NON-SENSOR COVER 1005886 1 1005886 1 1005886 1 1005886 2
12 NON-PRODUCT PROBE SEAL 1006871 1 1006871 1 1006871 1 1006871 2
13 CASTER SPACER 1007145 12 1007145 12 1007145 12 1007145 12
14 BRACKET, SENSOR MTG. 1008272 1 1008272 1 1008272 1 1008272 2
15 CORNER TUBE WELD 5002731 4 5002731 4 5002686 4 5002686 8
16 BOTTOM WELD ASSY —— —— —— —— —— —— 5005004 1
17 TUB SPOT —— —— —— —— —— —— 5005327 2
18 SPOT, INNER TUBE, BACK 5005986 1 5005405 1 5005327 1 5005327 2
19 LOWER FRONT FACADE SPOT —— —— —— —— —— —— 5006127 1
20 LOWER REAR ASSY —— —— —— —— —— —— 5006958 1
21 BONNET ASSY, SPOT 5009353 1 5009347 1 5009114 1 5009114 1
22 SENSOR MOUNTING BLOCK BK-27878 1 BK-27878 1 BK-27878 1 BK-27878 2
23 BUSHING, MALE CERAMIC —— —— —— —— —— —— BU-3105 8
24 BUSHING, FEMALE CERAMIC —— —— —— —— —— —— BU-3106 8
29 CABLE ASSY. 5006030 1 5005343 1 CB-3044 1 CB-3044 1
30 CONNECTOR —— —— —— —— —— —— CR-3226 8
31 CASTER, RIGID CS-25674 2 CS-25674 2 CS-25674 2 CS-24874 2
32 CASTER, SWIVEL W/ BRAKE CS-25675 2 CS-25675 2 CS-25675 2 CS-24875 2
33 GASKET ASSY, DOOR GS-23790 1 GS-22951 1 GS-22952 1 GS-22952 2
34 HANDLE, OFFSET MAG. LATCH HD-27080 1 HD-27080 1 HD-27080 1 HD-27080 2
36 HINGE HG-2015 1 HG-2015 1 HG-2535 1 HG-2535 2
37 INSULATION IN-2003 1 IN-2003 1 IN-2003 1 IN-2003 2
43-44 RATING TAG LA-26348 2 LA-26348 2 LA-26348 2 LA-26348 2
47 NUT, 10-32, NF HEX MS, #18-8 S/S —— —— —— —— —— —— NU-2215 32
48 PROBE PR-34494 1 PR-34494 1 PR-34494 1 PR-34494 2
49 RIVET, BLIND, #43, LRG FLG, STNLS RI-2094 10 RI-2094 10 RI-2094 10 RI-2094 20
50 RIVET, #42 STAINLESS RI-2097 4 RI-2097 4 RI-2097 4 RI-2097 8
51 RIVET, BLIND, #44, STNLS RI-2100 12 RI-2100 12 RI-2100 12 RI-2100 12
52 SCREW, 8-32 X 1, NC PHILLIPS PAN —— —— —— —— —— —— SC-2069 4
53 SCREW, 3/4 PAN HD SC-2071 2 SC-2071 2 SC-2071 2 SC-2071 4
54 SCREW, 10-32 X 3/4, NF, PHIL, FLAT SC-2072 12 SC-2072 12 SC-2072 12 SC-2072 20
55 SCREW, 10-32 X 1-1/2, NF, PHIL, FLAT SC-2073 4 SC-2073 4 SC-2073 4 SC-2073 8
56 SCREW, 6-32 X 1/2, NC PHIL, FLAT SC-2239 2 SC-2239 2 SC-2239 2 SC-2239 4
57 SCREW, 8-32 X 1/2 PHIL SCREW SC-2425 4 SC-2425 4 SC-2425 4 SC-2425 12
58 SCREW, 8-32 X 1/4 PHIL SCREW SC-2459 15 SC-2459 15 SC-2459 15 SC-2459 25
59 SCREW, 8-32 X 1/2T-410PH PAN HD —— —— —— —— —— —— SC-25849 18
60 SLEEVE, 1 LONG, FIBER, HEAT TREAT —— —— —— —— —— —— SL-3063 8
61 SIDE RACK, CHROME SR-28402 2 SR-28404 2 SR-2120 2 SR-2120 4
62 STUD, 10-32 X 1 3/4, FULL THD, 18-8 —— —— —— —— —— —— ST-2439 8
63 TAPE, FOAM TA-25621 1 TA-25621 1 TA-25621 1 TA-25621 1
64 GASKET, SIDE PANEL GS-23622 4 GS-23622 4 GS-23622 4 GS-23622 4
65 SHELF, NICKEL CHROME SH-2107 2 SH-2105 3 —— —— —— ——
