holding c a b i n e t s • i n s t a l l a t i o n /o p e r a t i o n /s e r v i c e manual - pg. 29
SerVICe
*not shown
eXterIor PartS - SIngle CoMPartMent, DelUXe Control
MoDel > 500-S 750-S 1000-S 1200-S
IteM DeSCrIPtIon Part no. Qty Part no. Qty Part no. Qty Part no. Qty
1 BONNET TOP COVER 1011946 1 1011872 1 1011534 1 1011653 1
2 SCREW, 6-32 X 1/2, NC PHIL TRUSS M/S 18-8 S/S SC-2239 2 SC-2239 2 SC-2239 2 SC-2239 2
3 GASKETS, ADHESIVE,.125X.375 [lin ft] GS-23622 8 GS-23622 8 GS-23622 8 GS-23622 1
4 HI-LIMIT PROTECTION COVER 1003936 1 1003936 1 1003936 1 1003936 1
5 SWITCH, CIRCUIT BREAKER SW-34769 1 SW-34769 1 SW-34769 1 SW-34769 1
6 CORDSET, 120V CD-3232 1 CD-3232 1 CD-3232 1 CD-3232 1
CORDSET, 208-240V CD-3551 1 CD-3551 1 CD-3551 1 CD-3551 1
CORDSET, 230V CD-3922 1 CD-3922 1 CD-3922 1 CD-3922 1
7 BUSHING, STRAIGHT, STRAIN RELIEF BU-3964 1 BU-3964 1 BU-3964 1 BU-3964 1
8 REAR TRIM 1011944 1 1011873 1 1011618 1 1011752 1
9 TERMINAL BLOCK, SENSOR BK-33546 1 BK-33546 1 BK-33546 1 BK-33546 1
10 T-BLOCK BK-3019 1 BK-3019 1 BK-3019 1 BK-3019 1
11 INSULATION IN-22364 1 IN-22364 1 IN-22364 1 IN-22364 1
12 TERMINAL STRIP TM-33560 1 TM-33560 1 TM-33560 1 TM-33560 1
13 SIDE PANEL 1011945 2 1011871 2 1011619 2 1011759 2
14 BOTTOM PANEL 1010774 1 1010394 1 1009941 1 1011650 1
15 CASTER, 5" (127mm) RIGID CS-24874 2 CS-24874 2 CS-24874 2 CS-24874 2
16 CASTER, 5" (127mm) SWIVEL WITH BRAKE CS-24875 2 CS-24875 2 CS-24875 2 CS-24875 2
17* NOT SHOWN —— —— —— —— —— —— —— ——
18 HANDLE, OFFSET MAG LATCH HD-27080 1 HD-27080 1 HD-27080 1 HD-27080 1
19 DOOR ASSEMBLY 5013132 1 5012938 1 5012801 1 5012663 1
20 SCREW, 10-32 X 1-1/2, NF, PHIL,FLAT M/S,18-8 S/S SC-2073 6 SC-2073 6 SC-2073 6 SC-2073 6
21 SCREW, 10-32 X 3/4, NF PHIL, FLAT M/S, #18-8 S/S SC-2072 6 SC-2072 6 SC-2072 6 SC-2072 6
22 HINGE, 1-3/8 OFFSET, PAIR, CHROME HG-22338 1 HG-22338 1 HG-22338 1 HG-22338 1
23 SIDE RACK SR-2842 2 SR-28404 2 SR-2120 2 —— ——
PAN SLIDE, CHROME PLATED —— —— —— —— —— —— SR-24447 8
PAN SLIDE RAIL —— —— —— —— —— —— 1011741 4
24 CONTROL WITHOUT TIMERS 5012946 1 5012946 1 5012946 1 5012946 1
25 RELAY RL-33558 1 RL-33558 1 RL-33558 1 RL-33558 1
26 ELECTRIC CHASSIS 5012122 1 5012122 1 5012122 1 5012122 1
27 POWER SUPPLY BOARD BA-33554 1 BA-33554 1 BA-33554 1 BA-33554 1
28 T-STAT, HI-LIMIT TT-33476 1 TT-33476 1 TT-33476 1 TT-33476 1
29 SENSOR GUARD 1493 1 1493 1 1493 1 1493 1
30 SCREW, 6-32 X 1/2, NC PHIL, FLAT SC-2239 2 SC-2239 2 SC-2239 2 SC-2239 2
31 BLOCK, MOUNTING SENSOR BK-29605 1 BK-29605 1 BK-29605 1 BK-29605 1
32 SENSOR SN-33541 1 SN-33541 1 SN-33541 1 SN-33541 1
33* NON-PRODUCT PROBE SEAL 1006871 1 1006871 1 1006871 1 1006871 1
34* INNER BACK PANEL 1011938 1 1011861 1 1011529 1 1011654 1
35* BEEPER BP-3567 1 BP-3567 1
BP-3567 1 BP-3567 1
36* BUSHING, 1/2" HOLE BU-3006 1 BU-3006 1 BU-3006 1 BU-3006 1
37* BUSHING, 1 1/8" SNAP BU-3378 4 BU-3378 4 BU-3378 4 BU-3378 4
38* BUSHING, 3/8" HOLE, BLACK BU-3419 1 BU-3419 1 BU-3419 1 BU-3419 1
39* NUT, HEX #8-32 NU-2296 2 NU-2296 2 NU-2296 2 NU-2296 2
40* PANEL, OVERLAY PE-27934 1 PE-27267 1 PE-27082 1 PE-28366 1
41* PLUG, 3/8" HOLE PG-25574 3 PG-25574 3 PG-25574 3 PG-25574 3
42* RIVET, BLIND, #44, STNLS RI-2100 24 RI-2100 24 RI-2100 24 RI-2100 24
43* SCREW, 10-32 X 3/4 PHILLIPS PAN HD SC-2071 2 SC-2071 2 SC-2071 2 SC-2071 2
44* SCREW, 10-32 X 1/4 PAN HD GROUND SC-2190 1 SC-2190 1 SC-2190 1 SC-2190 1
45* SCREWS, M4-0.7 X 6MM PHIL SC-22271 2 SC-22271 2 SC-22271 2 SC-22271 2
46* SCREW, 1/4-20 X 1/2, NC SLOT RND SC-2332 4 SC-2332 4 SC-2332 4 SC-2332 4
47* SCREW, 6-32 X 1-1/4 ROUND HD SC-2365 2 SC-2365 2 SC-2365 2 SC-2365 2
48* SCREW, 8-32 X 1/4 PHIL SC-2459 29 SC-2459 31 SC-2459 27 SC-2459 31
49* SCREW, 10-32 X 1-3/4, NF, PHIL, FLAT M/S,18-8 SC-29387 4 SC-29387 4 SC-29387 4 SC-29387 4
50* SHELF, CHROME PLATED SH-2107 2 SH-2105 2 —— —— —— ——
51* SWITCH, REED SW-33559 1 SW-33559 1 SW-33559 1 SW-33559 1
52* TAPE, 1" WIDE X 25 MIL VHB TA-24637 2 TA-24637 2 TA-24637 2 TA-24637 2
53* WASHER, STAR LOCK WS-2467 1 WS-2467 1 WS-2467 1 WS-2467 1
C
