E L E C T R O N I C C O N T R O L O P T I O N - 5 0 0 - S , 7 5 0 - S , 1 0 0 0 - S
S E R V I C E
500-S, 750-S, 1000-S, 1000-UP • INSTALLATION/OPERATION/SERVICE MANUAL • 31.
M O D E L S
5 0 0 - S , 7 5 0 - S , 1 0 0 0 - S , 1 0 0 0 - U P
C A B L E H E AT I N G S E R V I C E K I T
No. 4874
INCLUDES:
CB-3044 Cable Heating Element . . . . . . . . . .108 feet
CR-3226 Ring Connector . . . . . . . . . . . . . . . . . . . . .4
IN-3488 Insulation Corner . . . . . . . . . . . . . . . .1 foot
BU-3105 Shoulder Bushing . . . . . . . . . . . . . . . . . . . .4
BU-3106 Cup Bushing . . . . . . . . . . . . . . . . . . . . . . .4
ST-2439 Stud . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
NU-2215 Hex Nut . . . . . . . . . . . . . . . . . . . . . . . . . . .8
SL-3063 Insulating Sleeve . . . . . . . . . . . . . . . . . . . .4
TA-3540 Electrical Tape . . . . . . . . . . . . . . . . . . .1 roll
D A N G E R
DISCONNECT UNIT FROM
POWER SOURCE BEFORE
CLEANING OR SERVICING.
I T E M PA R T N O . D E S C R I P T I O N Q T Y I T E M PA R T N O . D E S C R I P T I O N Q T Y
1 1003936 HI-LIMIT PROTECTION COVER 1 PE-26567 PANEL CONTROL BEZEL, 1000-S 1
2 1005836 HEAT SINK 1 19 PE-27934
OVERLAY, ELEC, 500-S
1
3 5006075 BONNET SPOT ASSBY, 500-S 1 PE-27267
OVERLAY, ELEC, 750-S
1
5004770 BONNET SPOT ASSBY, 750-S 1 PE-27082
OVERLAY, ELEC, 1000-S
1
5005031 BONNET SPOT ASSBY, 1000-S 1 20 PG-25574 3/8" HOLE , 120V ONLY 1
4 5007164 HI-LIMIT BULB COVER, SPOT 1 21 PG-28439
P
LUG, DOME,.187" HOLE, 500-S, 750-S
4
5 BA-33554 POWER SUPPLY 1 22 PG-3559 7/8" HOLE PLUG, 500-S, 750-S 1
6 BK-3019 T-BLOCK 1 PG-3325 1.125" HOLE PLUG, 1000-S ONLY 1
7 BP-3567 BEEPER 1 23 PG-3589 PLUG,HOLE,13/16 1
8 BU-3008 3/4" WHITE SNAP BUSHING, 500-S 1 24 RL-33558
RELAY, SPST 30A @ 277 VAC 12VDC
1
BU-3378 1-1/8" SNAP BUSHING, 750-S 1 25 SC-2190
10-32 X 1/4 PAN HD GROUND SCREW
1
9 BU-3964
B
USHING,STRAIGHT,STRAIN RELIEF
4 26 SC-22271 SCREWS,M4-0.7X6MM PHIL 2
10 CC-34322 ELECTRONIC CONTROL, 230V 1 27 SC-22500 SCREW 6-32 X 1/4" PAN HD 2
CC-34324 ELECTRONIC CONTROL, 120V 1 28 SC-2365 SCREW,6-32X1-1/4,NC PHILLIPS 2
11 CD-3922 CORDSET, 16AWG, 3C, 230V 1 29 SC-2459 8-32 X 1/4" PHIL SCREW 5
CD-3232 CORDSET, 14/3 SJTOW, 120V 1 30 SC-2472 SCREW,6-32 X1/2,NC PHIL TRUSS 2
12 CL-22820 CANOE CLIP 1 31 SC-25849 SCREW,8-32X1/2T-410PH PAN HD 2
13 CR-33718 CONNECTOR 9 PIN 2 32 SW-34077 SWITCH, CIRCUIT BREAKER, 20 A 1
14 CR-33761 CONNECTOR, 7 PIN 1 33 TA-25621 TAPE 1
15 CR-33763 CONNECTOR 4 PIN 1 34 TM-33560 TERMINAL,STRIP,5CIRCUIT,UL,VDE 1
16 GS-2019 GASKET, 102" 1 35 TT-33476 T-STAT, 300 F HI-LIMIT 1
17 NU-2296 NUT, HEX #8-32 1 36 WS-2333 WASHER, #8 EXT LOCK 4
18 PE-26565 PANEL CONTROL BEZEL, 500-S 1 37 WS-2467 STAR LOCK WASHER 1
PE-26566 PANEL CONTROL BEZEL, 750-S 1
