MN-29756 (Rev. 4) 10/16 • TH-SK Series Cook, Hold, Smoke • 27
SINGLE COMPARTMENT COOK & HOLD
SERVICE
*not s hown
MODEL > 500-TH-II 750-TH-II 1000-TH-II
ITEM DESCRIPTION PART NO. QTY PART NO. QTY PART NO. QTY
1 FAN, BOX, 115V, 34CFM FA-3973 1 FA-3973 1 FA-3973 1
FAN BOX, 208-240V, 230V FA-34524 1 FA-34524 1 FA-34524 1
2 TOP COVER 1011946 1 1011872 1 1011534 1
3 GASKET ADHESIVE 0.125 X 0.375 [linear ft] GS-23622 1 GS-23622 1 GS-23622 1
4 PLUG, DOME, .187" HOLE PG-28439 6 PG-28439 6 PG-28439 6
5 BUSHING, STRAIN RELIEF BU-3964 1 BU-3964 1 BU-3964 2
6 SWITCH COVER 11133 1 11133 1 11133 1
7 REAR TRIM, SPOT 5014004 1 5014081 1 5014172 1
8 RIVET, BLIND, #44 STAINLESS STEEL RI-2100 6 RI-2100 6 RI-2100 6
9 PANEL, SIDE 5015081 2 5015083 2 5015088 2
10 SCREW, M4 X 0.7 X 6mm PAN SC-22271 17 SC-22271 19 SC-22271 25
11 CASTER PACKAGE 5008022 1 5008022 1 5014422 1
11A - CASTER, 3-1/2" (89mm) RIGID — — — — CS-25674 2
- CASTER, 2-1/2” (64mm) RIGID CS-28178 2 CS-28178 2 — —
11B - CASTER, 3-1/2" (89mm) SWIVEL W/ BRAKE — — — — CS-25675 2
- CASTER, 2-1/2” (64mm) SWIVEL W/ BRAKE CS-28179 2 CS-28179 2 — —
11C* - SHIM — — — — 1012735 4
12 BOTTOM PANEL 1010774 1 1010394 1 1009941 1
13 HINGE, PAIR HG-22338 1 HG-22338 1 HG-22338 1
14 DRIP TRAY KIT 5010736 1 5010391 1 5009716 1
- DRIP TRAY HOLDER 1010782 1 1010584 1 1010584 1
- DRIP TRAY 1010783 1 1010585 1 1010585 1
15 DOOR ASSEMBLY, RH 5010828 1 5010946 1 5010081 1
DOOR ASSEMBLY, LH 5010829 1 5010947 1 5010071 1
DOOR GASKET GS-22950 1 GS-22951 1 GS-22952 1
16 DRIP PAN WELD 14813 1 14831 1 5005616 1
17 SHELF, STAINLESS STEEL SH-2326 2 SH-2324 3 SH-2325 3
18 SIDE RACK, CHROME SR-28403 2 SR-28405 2 SR-2266 2
PAN SLIDES, 230V ONLY 1010880 2 1010813 2 — —
19 SCREW, M5 X 0.8 X 30mm FLAT SC-22853 10 SC-22853 10 SC-22853 10
20 HANDLE, OFFSET MAG. LATCH HD-27080 1 HD-27080 1 HD-27080 1
21 SCREW, M5 X 0.8 X 20mm PAN SC-22779 2 SC-22779 2 SC-22779 2
22 SHIM, HANDLE 13947 1 13947 1 13947 1
23 KNOB, THERMOSTAT KN-26568 2 KN-26568 2 KN-26568 2
24 THERMOSTAT, COOK TT-34910 1 TT-34910 1 TT-34910 1
25 SWITCH,ROCKER, 125-277V, 20A SW-34769 1 SW-34769 1 SW-34769 1
26 PANEL OVERLAY PE-29362 1 PE-29360 1 PE-28685 1
27 CONTROL CC-34488 1 CC-34488 1 CC-34488 1
28 CABLE, WIRE HARNESS CB-34945 1 CB-34945 1 CB-34945 1
29 SENSOR GUARD 1493 1 1493 1 1493 1
30 SCREW, M3 X 0.5 X 10mm FLAT SC-23102 2 SC-23102 2 SC-23102 2
31 BLOCK, CONTROL SENSOR BK-29605 1 BK-29605 1 BK-29605 1
32 PROBE, OVEN TEMP. SN-38111 1 SN-38111 1 SN-38111 1
33 SWITCH COVER (230V ONLY) CV-38297 1 CV-38297 1 CV-38297 1
34* NON-PRODUCT PROBE SEAL 1006871 1 1006871 1 1006871 1
35* CONNECTOR CR-34559 1 CR-34559 1 CR-34559 1
36* CONNECTOR-5 CONDUCTOR CR-34646 1 CR-34646 1
CR-34646 1
37* INSULA
TION IN-2003 1 IN-2003 1 IN-2003 1
38* NUT, HEX, M4-0.7 18-8 NU-22286 2 NU-22286 2 NU-22286 2
39* PLUG, 3/8" HOLE PG-25574 2 PG-25574 2 PG-25574 2
40* SCREW, M5 X 0.8 X 20mm FLAT SC-23868 6 SC-23868 6 SC-23868 6
41* 8-32 X 2 SLOT PAN HEAD 18-8 S/S SC-23154 2 SC-23154 2 SC-23154 2
42* SCREW, M3 X 0.5 X 16mm PAN SC-22270 8 SC-22270 8 SC-22270 2
43* WASHER M4 SPLIT LOCK S/S 18-8 WS-22300 2 WS-22300 2 WS-22300 2
44* SWITCH, VOLTAGE, 20A (230V ONLY)
— — — — SW-3528 1
