MN-29756 (Rev. 4) 10/16 • TH-SK Series Cook, Hold, Smoke • 13
SITE INSTALLATION
INSTALLATION
Drip tray installation instructions
Item Description Qty
A Double-Sided Tape 1
B Drip Tray Holder 1
C Screw, 8-32 x 1/4” Phil 3
D Drip Tray 1
1. Poke holes through double-sided tape A which is attached to the back of drip tray holder B.
2. Remove backing on double-sided tape A.
3. Put screws C through holes and attach drip tray holder B to unit.
4. Optional - apply a line of food-grade silicone caulk along top edge of drip tray holder B to seal.
5. Place drip tray D in drip tray holder B.
A
B
C
D
Drip Tray Installation
WARNING
Failure to properly install the
drip tray can or will cause major
equipment damage and will
result in a leakage hazard that
can cause personal injury.
