MN-29578 (Rev. 5) 10/16 • 1000-BQ2 Banquet Cart • 22
Cable Heating Replacement Service Kit ....... No. 4879
1000-BQ2/128 (208-240V) requires one (1) kit (120' of cable)
Service kit includes:
CB-3045 Cable Heating Element .....................................................112 feet
CR-3226 Ring Connector ............................................................................. 6
IN-3488 Insulation Corner .................................................................1 foot
BU-3105 Shoulder Bushing ......................................................................... 6
BU-3106 Cup Bushing .................................................................................. 6
SL-3063 Insulating Sleeve ........................................................................... 6
TA-3540 High Temperature Electrical Tape......................................1 roll
ST-2439 Stud 10.32 ....................................................................................... 6
NU-2215 Hex Nut........................................................................................ 12
Cable Heating Replacement Service Kit ....... No. 4881
1000-BQ2/96 (208-240V) requires one (1) kit (204' of cable)
1000-BQ2/128 (120V) requires two (2) kits (360' of cable)
1000-BQ2/192 (208-240V) requires one (1) kit for one (1) cavity or two (2)
kits for both cavities (204' of cable per cavity)
Service kit includes:
CB-3045 Cable Heating Element ....................................................210 feet
CR-3226 Ring Connector........................................................................... 12
IN-3488 Insulation Corner ................................................................. 1 foot
BU-3105 Shoulder Bushing ....................................................................... 12
BU-3106 Cup Bushing ............................................................................... 12
SL-3063 Insulating Sleeve ........................................................................ 12
TA-3540 High Temperature Electrical Tape .................................... 1 roll
ST-2439 10.32 Stud .................................................................................... 12
NU-2215 Hex Nut ....................................................................................... 24
Cable Heating Replacement Service Kit ....... No. 4880
1000-BQ2/96 (125V) requires one (1) kit (129' of cable)
1000-BQ2/192 (125V) requires one (1) kit for one (1) cavity or two (2) kits
for both cavities (129' of cable per cavity)
Service kit includes:
CB-3045 Cable Heating Element .....................................................134 feet
CR-3226 Ring Connector ............................................................................. 4
IN-3488 Insulation Corner .................................................................1 foot
BU-3105 Shoulder Bushing ....................................................................... 12
BU-3106 Cup Bushing .................................................................................. 4
SL-3063 Insulating Sleeve ........................................................................... 4
TA-3540 High Temperature Electrical Tape ....................................1 roll
ST-2439 10.32 Stud ....................................................................................... 4
NU-2215 Hex Nut.......................................................................................... 8
WARNING
Electric shock hazard.
Perform lockout/tagout procedures before
cleaning or servicing this appliance.
SERVICE
Cable Heating Service Kits
