Page 9
TME-M580 + Video and Navigation
3 pin EXT.PWR Cord
13 Pin Nav
Cable to
Alpine Navigation
3 Pin EXT
(if running
nav only)
8 Pin Din to
Monitor Brain
8 Pin to
Monitor
8 Pin Power
Harness
1
6
5
10
POWER
EX-2EX-1TD DISP.MIC/SW
GPS ANT.
13 Pin Nav Cable
(included with Alpine
Navigation systems)
VIDEO
Power Harness Color Code
5 Foot Brake (+)
6
Parking Brake (-)
7
Dimmer (+)
8
1
Ground
2
NOT USED
3
Accessory
4 NOT USED
IR Remote
Yellow/Black
Yellow/Blue
White/Blue
Black
OPEN
Red
OPEN
White/Brown
White Brown
Ext Box Front side Ext Box Back side
This cord is only used when using this
monitor as a navigation monitor only.
TO BRAIN
TO NAV
NOT USED
