Specications
Dynamic range ≥100dB
Signal to noise ratio (RCA) ≥100dB
Residual Noise
High level CH1~CH4: 58µVrms, CH5~CH8: 113µVrms, CH9~CH10:
115µVrms; RCA: 8.8µVrms
Channel Separation ≥80dB
THD ≤0.01%
Input voltage High level: 30Vpp; RCA: 6.5Vpp
Output voltage
High level CH1~CH4: 28Vpp, CH5~CH8: 40Vpp, CH9~CH10: 58Vpp;
RCA: 8Vpp
Rated power
CH1~CH4: 4CH x 25W, CH5~CH8: 4CH x 50W,
CH9~CH10: 2CH x 100W (4Ω, 14.4V, 1kHz, 10%THD),
CH9~CH10 Bridged: 1CH × 200W (4Ω, 14.4V, 1kHz, 10%THD)
Maximum power
CH1~CH4: 4CH x 50W, CH5~CH8: 4CH x 100W,
CH9~CH10: 2Ch x 200W (4Ω, 14.4V, 1kHz, 10%THD),
CH9~CH10 Bridged: 1CH x 400W (4Ω, 14.4V, 1kHz, 10%THD)
Input/output sensitivity (RCA) 1:1.23 (no power amplication)
Frequency response 20Hz ~ 20kHz
System sampling rate 48kHz/24bit
Input impedance High level: 18Ω; RCA: 15kΩ
Output impedance 51Ω
Supply Voltage 9 ~ 16V
Quiescent current ≤3mA (in o state)
Stand-by power consumption ≤0.1W
REM startup input High level (H1-/H1+), ACC optional
REM startup output 12V (0.2A)
Startup time 10s
Operating ambient temperature -20 ~ 60°C
Storage temperature -40 ~ 85°C
Net weight 3.9kg
Dimensions 250mm×234mm×50mm
12-EN
