7-EN
Basic Operation
Initial System Start-Up
Be sure to press the RESET switch when using the unit
for the first time, after installing the CD changer, etc., or
after changing the car battery.
1 Make sure that the power of the unit is off. If the power
is on, press and hold the POWER button for at least 3
seconds to turn off the unit.
2 Press the RESET switch with a ballpoint pen, or any
other pointed object.
Turning Power On and Off
1 Press the POWER button to turn on the unit.
NOTE
The unit can be turned on by pressing any other button except
the eject button.
The volume level gradually increases to the previous
level you were listening to before the unit was turned
off. Press and hold the POWER button for at least 3
seconds to turn off the unit.
NOTE
The very first time the power is turned on, the volume will start
from level 12.
Display Angle Adjustment
The movable display may be adjusted to 3 different
angles depending upon user preference.
1 Press the ANGLE button to adjust the angle of the
movable display.
NOTES
•
The adjusted angle of the display is stored in memory. There is
no need to re-adjust the angle when the power is turned back on.
• When the display is fully opened, if you turn off the ignition
key, after a while, the display will close fully. However, the
display will not fully close when the angle of the display has
been already stored in memory.
CAUTION
Keep hands (or any other object) away from the display while it
is opening or closing to avoid damage or injury. The back of the
movable display will get very warm under normal operating
conditions. This is not a malfunction. Do not touch.
•
The DVA-7996R can be operated using both the buttons
on the main unit and the included remote control unit
(except for some operations). The section on audio
operations (excluding DVD and video CD operations)
mainly describes operations using the buttons on the
main unit. For instructions on performing operations
using the remote control unit, see page 49.
• About Demonstration
This unit is equipped with a Demonstration function.
Soon after resetting the unit or after turning the unit on
the first time, the demonstration starts automatically.
To cancel the demonstration, refer to “Demonstration”
on page 18.
• Connectable to Remote Control Interface Box
You can operate this unit from the vehicle's control
unit when an Alpine Remote Control Interface Box
(optional) is connected. For details, contact your
Alpine dealer.
POWER
RESET
ANGLE
Detaching the Front Panel
1 Press and hold the POWER button for at least 3
seconds to turn off the power.
2 Press the (Release) button at left side until the front
panel pops out.
3 Grasp the left side of the front panel and pull it out.
NOTES
• The front panel may become hot in normal usage (especially
the connector terminals), this is not a malfunction.
• To protect the front panel, place it in the supplied carrying
case.
Attaching the Front Panel
1 First, insert the right side of the front panel into the
main unit. Align the groove on the front panel with the
projections on the main unit.
2 Push the left side of the front panel until it locks firmly
into the main unit.
NOTES
• Before attaching the front panel, make sure that there is no
dirt or dust on the connector terminals and no foreign object
between the front panel and the main unit.
• Attach the front panel carefully by holding the sides of the
front panel. This will help you to avoid pushing buttons by
mistake.
2
1
Movable display
