Je bekijkt pagina 8 van 24
4-EN
Basic Operation
Display Angle Adjustment
Movable display
The movable display may be adjusted to 3
different angles depending upon user preference.
1 Press the ANGLE 8 or 9 button to adjust the
angle of the movable display.
NOTES
• The display will close a half minute after the ignition
key is turned to the OFF position.
• The adjusted angle of the display is stored in memory.
There is no need to re-adjust the angle when the
power is turned back on.
CAUTION
Keep hands (or any other object) away from the display
while it is opening or closing to avoid damage or injury.
The back of the movable display will get very warm
under normal operating conditions. This is not a
malfunction. Do not touch.
Subwoofer On and Off
1 Press and hold the INTLZ button for at least 3
seconds.
2 Press the Preset 4 button.
With each press, subwoofer is toggled On or Off.
3 Press the INTLZ button to cancel the setting
mode.
NOTES
• Initial mode is "Subwoofer OFF."
• Set to "Subwoofer OFF" unless the subwoofer is
used.
• When the subwoofer is turned on, the subwoofer
output level can be adjusted. For more details, refer
to the Adjusting Volume/Bass/Treble/Balance/Fader.
Adjusting Source Signal Levels
If the difference in volume level between the CD
changer and FM radio is too great, adjust the FM
signal level as follows.
1 Press and hold the INTLZ button for at least 3
seconds.
2 Press the Preset 1 button to select the FM signal
level HI (High) or LO (Low) to make the signal
levels between the FM band and CD changer
closer.
3 Press the INTLZ button to cancel the setting
mode.
Adjusting Volume/Bass/Treble/
Balance (Between Left and Right)/
Fader (Between Front and Rear)
1 Press the MODE (Audio Control) knob
repeatedly to choose the desired mode.
Each press changes the modes as follows:
NOTES
• If the MODE (Audio Control) knob is not rotated in 5
seconds after selecting the BASS, TREBLE,
BALANCE, or FADER mode, the unit automatically
sets in the VOLUME mode.
• When the subwoofer, BBE mode is set to ON, the
level of the subwoofer, BBE can be adjusted.
2 Rotate the MODE (Audio Control) knob until the
desired sound is obtained in each mode.
NOTE
The settings of the Bass and Treble will be individually
memorized for each source (FM, MW (LW) and CD
changer) until the setting is changed. Depending on the
connected devices, some functions and display
indications do not work.
→ VOL → BASS →TREB
FAD ← BAL ←
MODE
BBE
f UP
INTLZ/DISP
B.C.14
DN g
9
8
