EN - 10

3. Fill with fuel before using the machine. For

preparing the mixture, refuelling methods

and precautions (see paragraph 7.2, 7.3).

4. wear the harness correctly

(see paragraph 6.1.1).

6.1.1 Using harnesses

The belts must be adjusted to suit

the operator’s height and build.

Always use a harness that is suited

to the weight of the machine:

– for machines weighing less than 7.5 kg,

single or double belt models can be used;

– the double belt model must be used for

machines weighing more than 7.5 kg.

• Models with single belt

The harness must be put on before connecting

the machine to the special coupling.

The belt (Fig. 19.A) must go from the

left shoulder to the right hip.

The belt must be worn with:

– the machine’s support (Fig. 19.A.1),

the snap-hook (Fig. 19.A.2) and

the quick release (Fig. 19.A.3)

coupling on the right side;

• Models with double belt

The harness must be put on before connecting

the machine to the special coupling.

The belt (Fig. 19.B) must be worn with:

– the machine’s support (Fig. 19.B.1),

the snap-hook (Fig. 19.B.2) and

the quick release (Fig. 19.B.3)

coupling on the right side;

– the quick release in front (Fig. 19.B.3);

– the belts cross-over on the

operator’s back (Fig. 19.B.4);

– the buckles properly fastened (Fig. 19.B.5).

The belts must be tensioned so that the load

is evenly distributed on the shoulders.

• Models with back-pack harness

Harness with back-pack must be

worn after starting the machine.

The harness (Fig. 19.C) must be worn with:

– the harness straps on the operator’s

shoulders (Fig. 19.C.1);

– the buckles properly fastened (Fig. 19.C.2).

– the snap-hook coupling on the

right side (Fig. 19.C.3);

– the quick release in front (Fig. 19.C.4).

The belts must be tensioned so that the load

is evenly distributed on the shoulders.

6.2 SAFETY CHECKS

Run the following safety checks and

check that the results correspond to

those outlined on the tables.

Always carry out the

safety checks before use.

6.2.1 General check

Object Result

Handles (Fig. 1.F;

Fig. 1.G , Fig. 1.I)

Clean, dry and xed

rmly to the machine.

Cutting means

guard. (Fig. 1.E)

Suitable for the cutting

means used, xed

correctly and rmly to

the machine, not worn/

deteriorated or damaged.

Connection point of

the harness (Fig. 1.J)

Correctly positioned.

Quick release (Fig. 19.A.3;

19.B.3, Fig. 19.C.4)

Ecient. Must enable

the machine to be

freed rapidly in the

event of danger.

Screws on the machine

and on the cutting means

Correctly tightened

(not loose)

Cutting means (Fig. 1.D.1;

Fig. 1.D.2, Fig. 1.D.3)

Not damaged or worn.

Metal blade (if tted)

(Fig. 1.D.2, Fig. 1.D.3)

Sharp

Air lter (Fig. 29.C,

Fig. 30.C, Fig. 31.C)

Clean

Electric cables and

spark plug cable

Undamaged to

prevent sparks.

Spark plug cap

(Fig. 18.H;)

Undamaged and tted

correctly on the spark plug

6.2.2 Machine operating test

Action Result

Start the machine

(par. 6.3)

The cutting means

(Fig. 1.D.1, Fig. 1.D.2,

Fig. 1.D.3) must not

move when the engine

is running idle.

Push the throttle control

lever (Fig. 18.B) and the

throttle safety lever at the

same time (Fig. 18.C).

The levers must move

freely and not be forced.
