31
Setting up the monitor
Using the tilt, swivel, pivot and height adjustment (AW2725DM)
NOTE: The following instructions are applicable only for attaching the stand that was shipped with your monitor. If you are
attaching a stand that you purchased from any other source, follow the setup instructions that were included with the stand.
Tilt and swivel adjustment
With the stand attached to the monitor, you can tilt and swivel the monitor for the most comfortable viewing angle.
20°
20°
5° 21°
Figure 19. Tilt and swivel adjustment
NOTE: The stand assembly is not pre-installed when the monitor is shipped from the factory.
Height adjustment
NOTE: The stand extends vertically up to 110 mm. The following image illustrates how to adjust the stand vertically.
110 mm
Figure 20. Height adjustment
Pivot adjustment
Before you rotate the display, ensure it is completely extended vertically and completely tilted up to avoid hitting the bottom edge
of the monitor.
1
2
Figure 21. Completely extend the monitor vertically and then tilt upwards
