10
ALF-VM52
5
LOGO1/LOGO2
(Logo)
Press to turn on/off "LOGO" overlay;
PIP1/PIP2
(Picture-in-Picture)
Press to turn on/off the "Picture-in-Picture" layer, press and
hold to enter the editing mode; the button backlight will flash.
Adjust the position and size of the picture-in-picture by turning
the "Menu Knob", adjust the position with the “Joystick”.
DSK (Downstream
Key)
Press to turn on/off Downstream (Caption) Keying;
CHROMA (Chroma
Key)
Press to turn on/off Chroma Keying;
6
FOCUS (Focus
Adjustment Knob)
Rotate to adjust the camera's focal length (Set the focus mode to
‘manual focus’ for the adjustment to take effect);
AF (Auto Focus)
Press to toggle manual/autofocus modes;
7
ZOOM TELE/WIDE
(Zoom Rocker
Switch)
Controls camera zoom (TELE: zoom in; WIDE: zoom out). The
Zoom Speed depends on pressure
8
WIPE (Wipe
Transition)
Press and hold to enter the wipe effect selection menu, tap to
activate the selected transition effect, the default effect is "Mix";
MIX (Mix
Transition) DIP (Dip
Transition)
Press to activate ‘Mix’ or ‘Dip’ transitions.
TIME (Transition
Time)
Press to select the Transition time and adjust with the ‘Menu
Rotary’ knob;
9
POS 1~4 (Presets)
Long press to set preset 1~4, short press to call preset 1~4;
10
CAM 1~4 (Camera
Selection)
Press to select camera 1~4; press and hold to enter the selected
camera menu settings;
11
PGM 1~4 (Program
Source Switch)
Press to select the source of the "PGM" channel 1~4;
12
PVW 1~4 (Preview
Source Switch)
Press to select the source of the "PVW" channel 1~4;
13
Menu Rotary Knob
In ’Menus’; rotate to adjust menu parameters; Press to Select /
Confirm.
In Camera mode: Adjusts pan/tilt speed.
In PIP mode: Adjusts PIP size.
In Audio mode: Adjusts audio parameters.
MENU
Press to open/close settings menu;
Long-press to open/close the camera settings menu;
14
AUX (AUX Source)
Press the "AUX" source to switch the Aux source to the "PVW"
channel;
PAT (PAT Source)
Press the "PAT" source to switch the background pattern to the
"PVW" channel;
15
CUT (Hard Cut)
Cuts (Transitions) PVW and PGM without any transition effect;
AUTO (Transition)
Transitions PVW and PGM with selected transition effects;
16
FADER /
FADER
LIGHT
Fader light indicates fader progress; The Fader controls manual
transition effects.
17
JOYSTICK
In camera mode: Controls pan/tilt (up/down/left/right) and zoom
(rotation). Press center button to ‘HOME’ the camera back to
the
camera’s initial position.
In PIP mode: Adjusts PIP position.
In audio mode: Switch audio channels left/right.
