Alfatron ALF-XXX-SDI/W
26
Select users: Set the user type (the default administrator, Common User 1, Common User 2 optional)
Username: Set the username (Select User Administrator default admin; select a common user1 default user1; to select a common
user 2 default user2; user can modify their own)
Password: Set a password (Select User Administrator default admin; select a common user1 default user1; to select a common user 2
default user2; user can modify their own).
Password confirmation: Confirm the input passwords are the same or not.
Click on the "Save" button to display the "Save successfully" message, then the setting will take effect.
Note: Please note the case-sensitivity of the username and password.
If login page by a common user’s name and password, one does not have configuration privileges but can only operate to preview,
playback, logoff.
4) Version upgrade
MCU version V3.0.1 2021-01-07
Camera version V1.0.4 2021-01-07
Focus version V4.0.4 2015-12-11
Users only read the version information above which is consistent with the menu version but cannot modify.
Update file:
Click "Browse ..." installation, to select the upgrade file in the pop-up window.
Click on the "Upgrade" button, the upgrade dialog will appear. The device will reboot automatically after updating successfully.
(Note: Ensure the power and network is kept connected during the process or the upgrade will fail)
Note: After the version upgrade is complete, you need to restore factory defaults. Through web to restore the factory default
configuration, or through the recovery menu, or remote-control shortcut “* # 6”
Choose one of the above three ways. If the first option is chosen, the IP accounts and passwords also need to be restored to the
default.
5) Restore factory setting
Click on pop-up "Restore Factory Defaults" button and choose “yes” or “no”, then the device will restart automatically and restore to
factory default setting.
6) Reboot
Click on the pop-up "Reboot" button and choose “yes” or “no”, then the device will restart automatically.
4.2.8 Logout
Point "Logout" pop-up "Confirmation" dialog; select "Yes" or "No", select “Yes” to exit the current page and return to the user login
interface again.
