22
ALFATRON ALF-12X-NDIC, ALF-20X-NDIC and ALF-30X-NDIC
4.2.2
Preview
After successful login into the management interface, it enters the video preview interface. In the preview screen, users
can control PTZ, zoom, focus, video capture, sound, focus, full screen and set the preset position, run, delete and other
operations.
You can record the video and save it on SD Card when SD Card built in. Video can be saved on the Computer at Local.
1) Login as administrator
Username, password, the default admin
PTZ control can be carried out, zoom, focus, video capture, sound, zoom, full screen and set the preset position, run, and
delete; you can preview, playback, configuration, log off.
2) Login as normal user
Default Username/password: user1 or user2
PTZ control can be carried out, zoom, focus, video capture, sound, zoom, full screen and set the preset position, un, and
delete; you can preview, playback and log off.
NOTE: There is no configuration right for normal user login.
4.2.3
Playback
1) Playback video files
First, please record, snapshot and save the file when previewing. Click "Playback" to enter recording file and picture files
playback page, and then select the file "Video File" and click Search, and search out the video file, click Play to play the
video file.
2) Playback picture files
First, please record, snapshot and save the file when previewing. Click "Playback" to enter recording file and picture files
playback page, and then select the file "Image File" and click Search, and search out the video file, click Play to play the
image file.
4.2.4
Configuration
Click Configuration to enter the device parameters setting page
There are the following options: Local configuration, audio configuration, video configuration, network configuration,
internet access configuration, system configuration, detailed description please see the following table.
Menu Explanation
Local configure
Including video preview mode, record video packing time, record video storage route settings
etc.
Audio configure
Including audio compressing format, sampling frequency, sampling precision, compressing
code rate settings etc.
Video configure
Including video encoding, video parameters, character-overlapping, character size, video
output setting etc.
Network configure Including basic parameters, Ethernet, DNS, network setting, GB28181 etc.
System configure
Including equipment property, system time, user management, version update, Reset,
Reboot device settings etc.
1) Local configuration
Video Preview Mode: user can choose real-time priority or fluency priority: The delay will be small when under real
time priority mode and fluency will be good when under fluency priority mode. Setting based on the user need (Default
value: real time normal (2), real time best (1), fluency normal (3), fluency good (4) and fluency best (5))
Recording packing time(minute): Set recording video packing time (default is 10, range from 1~120 minutes)
Recording/Snapshot file storage route: Set local recording video/snapshot file storage route. (Default
D:\MyIPCam\)
Click the Save button to make settings effective.
2) Audio Configuration
