Je bekijkt pagina 38 van 55
ALF-12-20X-HD-TC and ALF-12-20X-SD-TC
35
Focus
Auto/manual
Aperture
Auto/manual
Electronic shutter
Auto/manual
Backlight compensation
On/off
Wide dynamic
Off/dynamic grade adjustment
Video regulation
Brightness, hue, saturation, contrast ratio, sharpness, Gamma
Signal to noise ratio
>55dB
Panoramic lens
Image sensor
1/2.8inch high-quality CMOS sensor
Effective pixels
2,100,000
Lens
Manual focus
Output port
SDI Model: SDI, LAN,
HDMI/ USB Model: HDMI, USB3.0, LAN
Field angle (D/H/V)
112°/82°/57.6°
Input/output port and support protocol
Ports
SDI Model: SDI, LAN, 2-channel 3.5mm linear audio input, RS232 (input)
HDMI/USB Model: HDMI (support video and audio output), USB3.0, LAN, 2-
channel3.5mm linear audio input, RS232 (input)
Network port
100M internet access (10/100BASE-TX) 5GWiFi(optional), support network VISCA
control protocol
Network protocol
R T S P, R T M P, ONVIF, GB/T28181
Compression image code
stream
Dual-stream output
Video compression
format
H.265, H.264
Control signal port
RS-232/485
Control protocol
VISCA/Pleco-D/Pelco-P; Baud rate: 115,200/9,600/4,800/2,400bps
Audio input port
Dual track 3.5mm linear input
Audio compression
format
AAC, MP3, PCM
Power port
HEC3800 power socket (DC12V)
Pan/tilt parameters
Horizontal rotation
-170°~+170°
Vertical rotation
-30°~+90°
