ALFATRON ALF-5/10/12/20X/30X-CAM
12
Video Format
HDMI/ video format
1080P60/50/30/25/59.94/29.97;1080I60/50/59.94;720P60/50/30/25/59.94/29.97
interface video format
1)1920X1080P60/50/30/25;1280X720P60/50/30/25;960X540P30;640X360P30;640X480P30;352X
288P30;960X540P30;
Optical Zoom
5X
f＝3.6～18mm
10X
f＝4.7～47mm
12X
f ＝ 3.9 ～
46.1mm
20X
f＝5.2～98mm
30X
f＝4.3～129mm
View Angle
16.43°
（
tele
）
80.9°
（
wide
）
6.43°
（
tele
）
60.9°
（
wide
）
6.3°
（
tele
）
72.5°
（
wide
）
3.2°
（
tele
）
55.8°
（
wide
）
2.34°(tele)
65.1°(wide)
AV
F1.8 – F2.8
F1.6 – F3.0
F1.8 – F2.4
F1.5 – F3.0
F1.6 - F4.7
Digital Zoom
10X
Minimum Illumination
0.5Lux (F1.8, AGC ON)
DNR
2D & 3D DNR
White Balance
Auto / Manual/ One Push/ 3000K/ 4000K/5000K/6500K
Focus
Auto/Manual
Aperture
Auto/Manual
Electronic Shutter
Auto/Manual
BLC
ON/OFF
WDR
OFF/ Dynamic level adjustment
Video adjustment
Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
SNR
>55dB
Input/output Interface
Video Interfaces
ALF-5/10/12/20/30X-CAM USB2.0, USB3.0, HDMI, LAN, RS232（input）
Image code stream
Double streams output simultaneously
Video Compression
format
H.264, H.265
Control Signal Interface
RS-232 Ring through RS232 output, RS-485
Control Protocol
VISCA/Pelco-D/Pelco-P; Baud Rate: 115200/9600/4800/2400bps
HD IP Interface
100M IP port(100BASE-TX); support IP Visca control protocol
Network Protocol
RTSP/RTMP,ONVIF
Power Interface
HEC3800 outlet (DC12V)
PTZ Parameter
Pan Rotation
±170°
Tilt Rotation
-30°
～
+90°
Pan Control Speed
0.1 -180°/sec
Tilt Control Speed
0.1-80°/sec
Preset Speed
Pan: 60°/sec, Tilt: 30°/sec
Preset Number
255 presets (10 presets by the remote controller)
Other Parameter
Supply Adapter
AC110V-AC220V to DC12V/2A
Input Voltage
DC12V±10%
Input Current
1A(Max)
Consumption
12W (Max)
Store Temperature
-10℃ to +60℃
Store Humidity
20% - 95%
Working Temperature
-10℃ to +50℃
Working Humidity
20%--80%
Dimension
150mmX150mmX167.5mm
Weight
1.4KG
Working Environment
Indoor
Remote Operation (IP)
Remote Upgrade, Reboot, and Reset
Accessory
Power Supply
、
RS232 Control Cable
、
USB3.0 Cable
、
USB2.0 Cable
、
Remoter
、
Manual
、
Warranty
card
Wall or Ceiling Bracket
