ALFATRON ALF-5/10/12/20X/30X-CAM
26
4.2.2
Preview
After successful login into the management interface, it enters the video preview interface. In the preview screen, users can
control PTZ, zoom, focus, video capture, sound, focus, full screen, and set the preset position, run, delete, and other operations.
You can record the video and save it on SD Card when SD Card built-in. Video can be saved on the Computer at Local.
1) Login as administrator
User name, password, the default admin
PTZ control can be carried out, zoom, focus, video capture, sound, zoom, full screen and set the preset position, run, and delete; you
can preview, playback, configuration, log off.
2) Log in as a normal user
Default User name/password: user1 or user2
PTZ control can be carried out, zoom, focus, video capture, sound, zoom, full screen and set the preset position, un, and delete; you
can preview, playback, and log off.
NOTE: There is no configuration right for normal user login.
4.2.3
Playback
1) Playback video files
First, please record, snapshot, and save the file when previewing. Click "Playback" to enter the recording file and picture files
playback page, and then select the file "Video File" and click Search, and search out the video file, click Play to play the video file.
2) Playback picture files
First, please record, snapshot, and save the file when previewing. Click "Playback" to enter the recording file and picture files
playback page, and then select the file "Image File" and click Search, and search out the video file, click Play to play the image file.
4.2.4
Configuration
Click Configuration to enter into the device parameters setting page
There are the following options: Local configuration, audio configuration, video configuration, network configuration, PTZ
configuration, internet access configuration, system configuration, detailed description see the following table.
Menu Explanation
Local configure Including video preview mode, record video packing time, record video storage route settings, etc.
Audio configure
Including audio compressing format, sampling frequency, sampling precision, compressing code rate
settings, etc.
Video configure
Including video encoding,video parameters,character-overlapping,character size,video output
setting etc.
Network configure Including basic parameters, Ethernet, DNS, wireless network setting, GB28181, etc.
System configure
Including equipment property,system time,user management,version update,Reset,Reboot device
settings etc.
1) Local configuration
Video Preview Mode: The user can choose real-time priority or fluency priority: The delay will be small when under real-time
priority mode and fluency will be good when under fluency priority mode. Setting based on the user need (Default value: real-time
normal (2), real time best (1), fluency normal (3), fluency good (4) and fluency best (5))
Recording packing time(minute): Set recording video packing time (default is 10, range from 1~120 minutes)
Recording/Snapshot file storage route: Set a local recording video/snapshot file storage route. (Default D:\MyIPCam\)
Click the Save button to make settings effective.
2) Audio Configuration
Switch: Choose to enable the audio or not.
Compressing format:Set audio compressing format and the device will reboot automatically after change (default
MP3,PCM,AAC optional)
Sampling frequency:Set sampling frequency and the device will reboot automatically after change (default 44100,16000,32000
and 48000 optional)
Sampling precision: Set sampling precision (default 16bits)
