ALFATRON ALF-5/10/12/20X/30X-CAM
11
2.2
Main Features
2.2.1
Camera Performance
The features include advanced ISP processing algorithms to provide vivid images with a strong sense of depth, high resolution, and
fantastic color rendition. It supports H.265/H.264 encoding which makes motion video fluent and clear even with less than ideal
bandwidth conditions.
1. Superb High-definition Image: It employs 1/2.8-inch-high quality CMOS sensor. Resolution is up to 1920x1080 with a frame rate of
up to 60 fps.
2. Various Optical Zoom Lens: It has a 5X/10X/12X/20X optical zoom lens for options. The 5X zoom lens is with an 80.9 ° wide view
angle without distortion.
3. Leading Auto Focus Technology: Leading autofocus algorithm makes the lens a fast, accurate, and stable auto-focusing.
4. Low Noise and High SNR: Low Noise CMOS effectively ensure high SNR of camera video.
Advanced 2D/3D noise reduction technology is also used to further reduce the noise while ensuring image sharpness.
5. Quiet PTZ: By adopting a high accuracy step driving motor mechanism, it works extremely quiet and moves smoothly and very
quickly to the designated position.
6. Multi-Format Video Outputs: support HDMI, USB, wired LAN
7. Multiple Remote Controls: There is IR remoter and 2.4G wireless remote for options. The 2.4G wireless remote controller will not
be affected by angle, distance, or IR interference. Support transparent transmission function.
8. Low-power Sleep Function: Support low-power sleep/wake up, the consumption is lower than 500mW under sleep mode
9.Support Multiple Control Protocol: Support VISCA, PELCO-D, PELCO-P protocols which can also be automatically recognized.
Support VISCA control protocol through the IP port.
10.RS-232 Cascade Function: ST series support RS-232 cascade function which is convenient for installing.
11.255 Presets Positions: Up to 255 presets (10 presets by remoter).
12.Wide Application: Tele-education, Lecture Capture, Webcasting, Videoconferencing, Tele-training, Tele-medicine, Interrogation,
and Emergency command systems.
2.2.2
Network performance
1. Audio Input Interface: Support 16000,32000,44100,48000 sampling frequency and AAC, MP3, PCM audio coding.
2. Multiple Audio/Video Compression: Support H.264/H.265 video compression; AAC, MP3, and PCM audio compression;
Support compression of resolution up to 1920x1080 with frame up to 60 fps and 2 channel 1920x1080p with 30 fps
compression.
3. Multiple network protocol: Support ONVIF, RTSP, RTMP protocols and RTMP push mode, easy to link streaming media server
(Wowza, FMS)
2.3
Technical Specification
Model
5X
10X
12X
20X
30X
Camera Parameter
Sensor
1/2.8-inch-high quality HD CMOS sensor
Effective Pixels
16: 9 2.07 megapixel
