Alecto CW20 handleiding
Handleiding
Je bekijkt pagina 4 van 7
Extra functions:
‘asterisk’ and ‘pound’ buttons:
the * and # buttons are used mainly for
tele-banking:
- press the * button when asked to press
the ASTERISK button
- press the # button when asked to press
the POUND button
R button
you can use the R button to accept or start
a 2nd call keep in
every telephone service
provider and that it most likely requires an
additional subscription
when connected to a switchboard, you can also
use this button to forward calls; for this, refer to
the user manual of your telephone switchboard or
the installer
Mute function
press the bracket according
to the illustration to
disassemble again
Wall-mounting:
1. in a vertical line, drill 2 holes at a distance of
10 cm from each other and insert plugs and
screws; let the head of the screws protrude for
5 mm
2. rotate the recei-
ver suspension
tab 180° accor-
ding to the pictu-
re; this tab will
hold the receiver when used in a suspended
position
3. hook the telephone with the screw holes over
the screws and press it downward
4. fix the phone line with cable-ties onto the wall
MEMORIES
Your phone has a memory for 10 phone numbers
up to 21 digits.
Programming:
1. Pick up the receiver and put it next to your
phone
2. press 1x the button
3. press M and the desired memory button (0-9)
under which you’d like to save the number
4. use the keypad to enter the desired phone
number
5. press 1x the button
6. put the receiver back onto the phone
Dialling:
1. pick up the receiver
2. press the M button followed by the numeric
button (0-9) under which you’ve saved the
number
Tips and remarks:
The phone uses the voltage of the telephone
connectors to store the memories, which means
you don’t need to insert batteries. However, make
sure to keep the phone connected at all times.
A brief interruption, e.g. for quickly moving the
phone, is possible without losing the memories.
A memory number may contain up to a maximum
of 21 digits.
In addition to normal phone numbers, you can
also store the numbers of mobile phones.
You can not Editing or deleting:
• You can change a number by programming
the new number over the old number. This
will overwrite and delete the old number.
• You can delete a number by programming a
non-existing number (e.g. 0000) over the old
number. This will overwrite and delete the old
number.
Ringtone
3. Pick up the receiver and put it next to your
phone
4. press 1x the
button
5. press 1x the # button
6. use the keypad to enter the desired Ringtone
(0-9)
7. press 1x the button
8. put the receiver back onto the phone
TIPS AND WARNINGS
GENERAL:
• Read the user manual carefully and follow all
instructions.
• Always disconnect the phone plug from the
phone socket before cleaning your phone.
• Never place or use the phone in a wet or
moist room or environment.
• Take care of proper heat dissipation; never
cover the phone and do not place them
directly beside a heat source.
• Take care that the cable of the phone and the
adapter do not get damaged, and prevent
that they cause tripping or falling.
• Never disassemble the phone and the
adapter; this may only be done by qualified
personnel.
INSTALLATION:
• Connect or disconnect the cables of the
phone only to the base station and the phone
connector has been disconnected from the
phone socket.
• Do not install the phone during a lightning
storm.
• Do not install a phone connection point in a
wet or moist environment.
• Do not touch uninsulated phone or adapter
cables, unless they are disconnected from
the phone network or the mains power.
ENVIRONMENT:
• The packaging of this telephone can
be collected as old paper. However,
we recommend you to save it, to
adequately protect the phone during
transport. When replacing this
telephone, please return it to the supplier to
ensure environment-friendly processing.
MAINTENANCE:
• Only clean the housing with a moist cloth,
never use chemical cleaning agents.
• Never place the CW20 onto cellulos e-treated
surfaces; the rubber feet could leave tracks.
WARRANTY
Name: Attach here your
Address: receipt or voucher
Post code:
City:
phone number:
Serial number:
(see the production label at the bottom of the
phone)
For the Profoon CW20 you have a warranty of
24 months from the date of purchase. During this
period, we guarantee the free repair of defects
caused by material and workmanship errors.
All this subjected to the final assessment of the
importer.
HOW TO HANDLE: If you notice any defect, first
refer to the user’s manual. If the manual provides
no definite answer, please contact the supplier of
this baby video monitor or contact the customer
service of PROFOON.
THE WARRANTY BECOMES NULL AND VOID:
In case of improper use, incorrect connections,
leaking and/or incorrectly installed batteries, use
of unoriginal parts or accessories, negligence
and in case of defects caused by moisture,
fire, flooding, lightning and natural disasters.
In case of unauthorised modifications and/or
repairs performed by third parties. In case of
incorrect transportation of the device without
adequate packaging and when the device is not
accompanied by this warranty card and proof of
purchase.
The warranty does not cover connecting cables,
plugs and batteries. All further liability, especially
concerning any consequential damages, is
excluded.
USER’S MANUAL
INSTALLATION
Receiver:
1. connect the receiver with the telephone by
attaching one side of the spiral cable to the
bottom of the receiver and the other side to
the left side of the telephone
2. push in the plugs until they’re securely
connected
Telephone:
1. plug the telephone wire into the bottom of the
telephone
2. insert the telephone plug into a telephone
wall socket
Desk bracket:
you can use the phone as a desk
model by clicking the bracket onto the
bottom of the phone according to the
illustration below
USING THE TELEPHONE
Receiving calls:
the call light illuminates when
you’re receiving a call
pick up the receiver to answer calls
Dialling numbers:
1. pick up the receiver
2. use the keypad to enter the phone number,
this number will be dialled directly
Ending calls:
1. put down the receiver to disconnect your call
Call signal:
1. pick up the receiver and wait for the dialling
tone
2. press the button to redial the last dialled
number
Memory dialling:
1. pick up the receiver
2. press the M button followed by the numeric
button (0-9) under which you’ve saved the
number
1
2
#
R
beep and the microphone in the handset
partner on the other side of the line can
no longer hear you.
- The phone light will blink
- You can still hear your conversation partner
-
hone back on.
V1.0
CW20
Alecto is a brand of Commaxx B.V.
Wiebachstraat 37, 6466 NG
Kerkrade, The Netherlands
Service / Help ?
www.alecto.nl
Suppor t.alecto.nl
