443683_a 29

Help in case of malfunction

7.2 Replacing the scarifier roller and

aeration roller (optional) (18)

The scarifier roller is intended for coarse scarify-

ing work and the aeration roller (optional) for fine

scarifying work (see chapter 2.6 "Scope of supply

(02, 03)", page22).

Removing the roller

1. Stop the appliance and wait until the blade

system has come to a standstill.

2. Disconnect the mains plug.

3. Turn the appliance over.

4. Loosen and remove the screw (18/1) (18/a).

5. Fold the locking bar (18/2) upwards (18/b).

6. Gently push the roller (18/3) towards the

housing (18/c).

7. Remove the roller (18/d).

Installing the roller

Proceed in the reverse order.

8 HELP IN CASE OF MALFUNCTION

CAUTION! Risk of injury. Sharp-edged

and moving appliance parts can lead to injury.

■

Always wear protective gloves during mainte-

nance, care and cleaning work!

NOTE For malfunctions that are not listed in

this table or that you cannot resolve yourself,

please contact our customer service.

Malfunction Cause Remedy

Motor does not start. No electric power

■

Check the mains cable and circuit

breaker.

■

Pull the motor switch lever/operator

presence control completely up

against the handlebar.

The blade system is blocked

by lawn thatch and moss.

■

Set a lower working depth.

■

Clean the blade system.

Immediate short-circuit on

inserting the mains plug

Defective electrical compo-

nents in the appliance.

■

Contact a customer service work-

shop.

The blade system does not

rotate.

The blade system is blocked

by lawn thatch and moss.

■

Set a lower working depth.

■

Clean the blade system.

Motor and scarifier perfor-

mance decreases.

The blade system is braked.

■

Set a lower working depth.

■

Mow the lawn.

Scarifier blades are worn.

■

Replace scarifier roller.

Appliance vibrates and

does not run smoothly.

Scarifier blades are dam-

aged.

■

Replace scarifier roller.

■

Contact a customer service workshop.

9 TRANSPORT

IMPORTANT! Risk of damage to the appli-

ance. The blade system will be damaged if the

appliance is moved over a solid surface with the

blade system lowered.

■

To raise the blade system, turn the adjuster

wheel for the working depth to Shallow scari-

fying.

1. Stop the motor and wait until the blade sys-

tem has come to a standstill.

2. Turn the setting wheel for the working depth

to the right to Shallow scarifying (12/2).

3. Remove the mains plug from the power sock-

et, fold up the mains cable.

Transporting the appliance between two

working areas

■

Move the appliance to the working area with

the blade system raised.

■

To carry the appliance: Lift the appliance by

the carrying handle.

Transporting the appliance in a vehicle

■

Fold in the handlebar (see chapter 6.1 "Fold-

ing the handlebar in and out (09)", page27).
