• Connect an RCA audio cable (not supplied) to the AUDIO LINE OUT sockets on the rear of the
turntable.
Note: Take care to match the RED/WHITE plugs to the corresponding RED/WHITE sockets.
• Connect the other end of the cable to an AUDIO INPUT on the amplifier (check your amplifier user
manual if you are not sure).
• The volume control on the turntable will have no effect on the volume level when connected this
way. All volume controls should be operated from the amplifier.
Note: Turn the volume on the turntable all the way down, so it does not interfere with the external
sound system.
Playing a record
Before use, ensure the security wire (tone-arm rest/lock) and the cartridge protector
(stylus/cartridge) have been removed. And the tone-arm lock is released.
• Place a record on the turntable platter.
• Select the speed required using the speed selector switch.
• Raise the tone-arm using the tone-arm lift lever. As you move the tone-arm towards the record
the turntable begins spinning. Lower the needle gently onto the outer edge of the record using
the tone-arm lift lever.
• Rotate the ON/OFF/Volume control knob to increase or decrease the volume level.
• When a record comes to the end, the turntable will stop automatically if the auto-stop switch is
in the “ON” position. If the switch is in the off position then it will keep revolving all the time.
• Lift up the tone arm and put it on the rest when finished.
• Replace the protective cap on the stylus and close the tone arm lock.
• Turn off power at mains.
USB flash drive and SD card reader Recording
(Lift up the tone arm and put it on the rest.)
LISTEN TO MUSIC:
• If you want to play or pause music from your installed SD card or USB flash memory, turn the
power & volume control knob clockwise to power on; the music will start playing automatically.
• You can play or pause music by pressing the play-pause/Del button.
• If you want to play the next or previous track from your installed SD card or USB flash memory,
press the next track or previous track button.
• If you have installed an SD card & USB flash memory, the last one installed will start playing. You
can select the desired source by pushing the MODE/REC button. (SD => USB). The mode button
will select the active/installed sources only. Only mp3 file format is supported.
Note: the tone arm must be in rest position.
RECORDING MUSIC:
You can convert your vinyl records into digital mp3 files by inserting an SD/MMC card in the SD/MMC
card reader slot or USB flash memory device into the USB port.
• Play your ‘vinyl’ music, as described in ‘listening to a record’.
• Press and hold the MODE/REC button for 2 seconds.
• You will hear one ‘short beep’, indicating that recording has started.
• When finished recording, press “MODE/REC” for 2 seconds to stop recording.
• You will hear 2 ‘short beeps’, indicating that the recording has stopped.
• The recorded songs will be saved in the “RECORD0” folder as mp3 file, in 128 kbps.
• The file names of the recorded songs will be “REC001L, REC002L, etc”.
• You can only switch folders between the “RECORD0” folder and the SD card and/or USB flash
memory by pressing the MODE/REC button (SD/MMC=> SD/MMC record0 => USB => USB record0
=> SD/MMC).
5
