RovoCam UltraHD HDBaseT Camera System v1.0r4 18 www.aja.com
Table 1. Recommended Cables for Ultra-HD video transmission
Type Manufactur er URL
CAT7 S/FTP Teldor http://www.teldor.com/
CAT6A H/STP Teldor http://www.teldor.com/
CAT.7 Earthline http://products.lappgroup.com/online-catalogue/data-
communication-systems-for-ethernet-technology/
Video Displays
Figure 9. HDBaseT Cable Run Performance for 4K/UltraHD/HD
W x H Frame Rate Color
Sampling
Max. Cable Length Max. Bit
Depth
Cat 5e/6 Cat 6a/7
1920 x 1080 < 30 fps 4:2:2 100 meters 100 meters 16-bit
> 30 fps
4:2:2 100 meters 100 meters 12-bit
4:2:2 70 meters 100 meters 16-bit
2048 x 1080 < 30 fps 4:2:2 70 meters 100 meters 16-bit
> 30 fps
4:2:2 100 meters 100 meters 12-bit
4:2:2 70 meters 100 meters 16-bit
3840 x 2160 < 30 fps 4:4:4 70 meters 100 meters 8-bit
> 30 fps 4:2:0 70 meters 100 meters 8-bit
4096 x 2160 < 30 fps 4:4:4 70 meters 100 meters 8-bit
> 30 fps 4:2:0 70 meters 100 meters 8-bit
