OG-X-FR openGear Frame v1.0r2 7 www.aja.com
Chapter 2 – Before You Begin
If you have questions pertaining to the operation of OG-X-FR, please contact us
at the numbers listed in the section "Contacting AJA Support" on page 2. Our
technical staff is always available for consultation, training, or service.
Overview
The OG-X-FR frame offers the flexibility of independent rear modules for
connectivity to a wide array of interfaces such as BNC, twisted-pair audio, and
fiber. Each frame offers a full rear module that accommodates one card each, or a
high density split rear module that accommodates two cards each. Using the split
rear module allows for up to 20 independent openGear solutions to be installed.
NOTE: Cards and rear modules designed for the DFR-8321 frames are also supported by
the OG-X-FR frames. However, some cards and rear modules may be designed
specifically for the OG-X-FR frames only. Refer to the documentation for your
openGear card for details on the frames you can use.
Features
The OG-X-FR frame includes the following features:
• Two independent looping reference inputs feed all card slots
• Can house any mix of analog, digital, video and audio cards in the same frame
• Available with individual card specic modules for connector exibility
• Optional redundant power supply is hot-swappable for 24/7 operation
• Power switch is accessible from front of the rack frame
• Power supplies are replaceable from the front of the frame without requiring
rear-frame access
• Separate power cords to each supply for power feed redundancy
• PowerLock cord retainer mechanism guards against accidental power loss
• Durable powder-coat paint nish
• Removable hinged front door for easy card insertion and removal, and
exibility in servicing the cooling fans
• Aluminum and steel construction to reduce weight and increase strength
• 2RU frame houses up to 20 cards
• Robust 500W power supply with two integral cooling fans per power supply
• Comes standard with the Cooling Fan Module for increased ventilation and
enhanced reliability
• Supports Gigabit ethernet connectivity to each openGear card in the frame
(requires the MFC-OG3-N Network Controller Card)
• Provides a system alarm LED on the frame front door
• Provides an LCD Diagnostic Panel on frame front that reports the frame name,
and IP address; provides the ability to scroll through these reported error
conditions
• Removable door with durable powder-coat paint nish
• 5-year warranty
