OG-X-FR openGear Frame v1.0r2 12 www.aja.com
Caution! Attempting to install an OG-X-FR frame rear module into an OG3-FR,
DFR-8321, DFR-8320, or DFR-8310 frame can damage the rear module.
Rear Module Types
This section provides an overview of the rear module types for your OG-X-FR
frame.
Full Rear Modules
The full rear modules features a single card connector and can include a
combination of BNC, WECO™, fiber optic, serial, and ethernet connectors. Each
module occupies two slots in the frame and accommodates one card. Ensure the
openGear card is installed in the correct slot in the OG-X-FR frame. Up to 10 cards
can be installed in a frame when using these modules.
Split Rear Modules
Much like the modules for the OG3-FR frames, split modules for the OG-X-FR
frame features two card connectors and can have a combination of BNC, WECO™,
fiber optic, serial, and ethernet connectors. Each card connector is routed to a
column of five BNCs. A split rear module occupies two slots in the OG-X-FR frame
but provides connectors for two openGear cards, allowing you to install up to 20
cards in the frame.
Blank Rear Modules
Blank Rear Modules (R2-BLANK) are used when the slot does not have an
openGear card installed. This helps to ensure proper frame cooling and
ventilation.
